2023 Trek
Domane+ AL 5
An aluminum frame endurance e-bike with upper mid-range components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
$3,499| Weight | 31.0 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 11 |
| Groupset | 105, FSA |
| Motor | 250W 40Nm hub-drive |
| Battery | 250Wh |
| Brakes | Hydraulic Disc |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Domane+ model range
View Comparison5'1" – 5'5"
5'3" – 5'7"
5'5" – 5'9"
5'8" – 6'0"
5'10" – 6'2"
6'0" – 6'4"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Dec 2023 · Matthew Pioro
Pedal assist can support your rides in surprising ways
Sep 2023 · Warren Rossiter
Endurance road bike classic fortified with powerful TQ mid-motor
Powerful motor
Smooth ride
Stable handling
Fast charging
Remote control brackets slip
Apr 2023
The lightweight and quiet Domane+ SLR proves that less can be more for e-road bikes.
Very light for an e-road bike
Clearance for tires up to 40mm
Smooth and very quiet motor
Pricey
Relatively small battery capacity
Nov 2022
Price: $12999.00 | Model Year: 2023 | An ultra light weight 28.5lb electric road bike with endurance comfort geometry and iso speed vibration dampening seat post interface. The first ebike to feature Trek's OCLV carbon fiber. Available in five colors and seven frame sizes.
An ultra light weight 28.5lb electric road bike with endurance comfort geometry and iso speed vibration dampening seat post interface. The first ebike to feature Trek's OCLV carbon fiber. Available in five colors and seven frame sizes.
This particular build uses top of the line SRAM components with a 1x12 drivetrain, flared drop bar, and 40c wide gravel tires. Alternative builds offer narrower road tires and a 2x12 Shimano drivetrain. SRAM Red electronic shifting and 160mm hydraulic disc brakes.
Hidden fender mounts add utility, integrated top top tube display panel works well and is easy to read, optional smartphone app provides motor tuning settings, optional range extending 160wh bottle shaped battery pack provides 40% more range and off-bike charging.
Excellent control pad button placement on left and right hood. Includes 4 amp fast charger despite having a lower capacity 360wh battery. Main battery not removable for charging and storage. Seat post is a proprietary shape so upgrade options are limited.
Oct 2022 · James Huang
Flagship model weighs just 12.21 kg, and US-spec bikes get a genuinely useful 45 km/h cutoff from the new TQ mid-drive motor.
Oct 2022 · Martin Staffa
With a new TQ-HPR50 mid-drive motor hidden inside its frame, the Trek Domane+ SLR 6 2023 goes e-ncognito, promising to deliver an authentic road bike feeling despite its electric motor. But does it actually work?
Balanced weight distribution and good handling
Excellent motor integration
Hardly perceptible noise level
Generous tire clearance
Mudguard mounts ensure good everyday suitability
Disproportionately thick down tube looks awkward
Oct 2022 · James Huang
Flagship model weighs just 12.21 kg, and US-spec bikes get a genuinely useful 45 km/h cutoff from the new TQ mid-drive motor.
Sep 2020
The new 2021 Trek Domane+ ALR e-road bike takes the same lightweight Fazua Evation system from the carbon bicycle, but wraps it in alloy.
| Frame | 100 Series Alpha Aluminum, hub drive system, tapered head tube, internal routing, flat mount disc, rack and fender mounts BB Standard: BSA, 68mm, Threaded Tire Clearance: 38c Colors: Trek Black; Viper Red; Mercury |
|---|---|
| Fork | Domane+ carbon, tapered alloy steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
| Bottom Bracket | Torque sensor, threaded, 110mm spindle |
| Headset | FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom |
| Stem | Size: 49, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 52, 54, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 56, 58, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: 61, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length |
| Handlebar | Size: 49, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width; Size: 52, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width; Size: 54, 56, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm width; Size: 58, 61, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width |
| Saddle | Size: 49, 52, Bontrager Verse Short Comp, steel rails, 155mm width; Size: 54, 56, 58, 61, Bontrager Verse Short Comp, steel rails, 145mm width |
| Seatpost | Bontrager carbon, 27.2mm, 8mm offset, 330mm length Type: Rigid |
| Rear Derailleur | Shimano 105 R7000, long cage, 34T max cog |
|---|---|
| Front Derailleur | Shimano 105 R7000, 31.8mm clamp |
| Crank | Size: 49, FSA Vero Pro, 50/34, 165mm; Size: 52, FSA Vero Pro, 50/34, 170mm; Size: 54, 56, FSA Vero Pro, 50/34, 172.5mm; Size: 58, 61, FSA Vero Pro, 50/34, 175mm |
| Shifters | Size: 49, 52, Shimano 105 R7025, short-reach lever, 11 speed; Size: 54, 56, 58, 61, Shimano 105 R7020, 11 speed |
| Cassette | Shimano 105 HG700-11, 11-34, 11 speed |
| Chain | Shimano HG601, 11 speed |
| Brakes | Shimano 105 hydraulic disc, BR-R7170 flat mount caliper, resin pad w/fin Type: Hydraulic Disc |
| Rims | Bontrager Paradigm, Tubeless Ready, 28-hole, 21mm width, Presta valve |
|---|---|
| Front Hub | Formula RX-812 alloy, sealed bearing, 6-bolt, 100x12mm thru axle |
| Rear Hub | Hyena hub drive motor, 40Nm, 250W |
| Tires | Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32c |
| Disc Rotors | Shimano RT66, 6-bolt, 160mm |
| Motor | Hyena hub drive motor, 40Nm, 250W |
|---|---|
| Battery | 250Wh, integrated in down tube, Range Extender compatible Recycling Program: ♻️ Call2Recycle |
| Charger | 2A, 42V output, 100V-240V AC input |
