2022 Trek
Madone SL 6
A carbon frame aero bike with high-end components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
$4,729| Weight | 19.3 lbs |
|---|---|
| Frame | Carbon |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 11 |
| Groupset | Ultegra |
| Brakes | Hydraulic Disc |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Madone model range
View Comparison4'11" – 5'3"
5'1" – 5'5"
5'3" – 5'7"
5'5" – 5'9"
5'8" – 6'0"
5'10" – 6'2"
6'0" – 6'4"
6'2" – 6'5"
Nov 2023 · Mat Brett
It had its idiosyncrasies – including flip-out 'Vector Wings’ in the head tube – but we wish every new bike offered as many interesting features as the Trek Madone 9 Series did back in 2015
Aug 2023 · Matt Hansen
Gen 7 model uses IsoFlow technology from SLR
Aug 2023 · Troy Templin
The Trek Madone SL Gen 7 now completes the line matching the more expensive SLR and offers almost the same ride quality.
May 2023 · Simon von Bromley
The seventh-generation Madone is an excellent all-round performer, but it comes with a big price tag
Composed yet fast
Innovative design
Front end can run both integrated and non-integrated handlebar setups
Wide range of frame sizes
Expensive
No power meter
Mid-range tyres and cheap inner tubes don’t belong on this bike
Dec 2022 · Sam Challis
The new Madone is leaner, meaner and wickedly quick
Very fast ride feel
Smart componentry design
Light weight
Comfort
Price
Narrow bars take some getting used to
Vulnerable in gusty conditions
Dec 2022 · Julian Schwede
Does the new IsoFlow system of the 2023 Trek Madone SLR 9 eTap Gen 7 really rise the bar in terms of aeroynamics and comfort?
Very balanced handling at high speeds
Reduced complexity and improved aerodynamics of the IsoFlow system
Customisation options thanks to the Project One configurator
High-quality workmanship
The damping of the IsoFlow system isn’t adjustable
The Bontrager R4 tires lack grip
Mar 2022 · Ben Delaney
The Greek god of the winds invoked at three points on the sprinter's bike.
Nov 2021 · James Huang
Unusually good ride quality and the handling is brilliant, but it’s hard not to notice the heft when you point it uphill.
Superb aerodynamics, comfy ride, excellent handling, accommodating cockpit design, threaded bottom bracket.
So-so front-end ride, so heavy.
| Frame | 500 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, T47 BB, flat mount disc, Duo Trap S compatible, 142x12mm thru axle BB Standard: T47, Threaded Tire Clearance: 28c Color: Viper Red |
|---|---|
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Stem | Size: 47, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: 50, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 52, 54, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 56, 58, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: 60, 62, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 110mm length |
| Handlebar | Size: 47, Bontrager Elite Aero VR-CF, alloy, 31.8 mm, invisible cable routing, 93 mm reach, 123 mm drop, 40 cm width; Size: 50, 52, Bontrager Elite Aero VR-CF, alloy, 31.8mm, invisible cable routing, 93mm reach, 123mm drop, 40cm width; Size: 54, 56, Bontrager Elite Aero VR-CF, alloy, 31.8mm, invisible cable routing, 93mm reach, 123mm drop, 42cm width; Size: 58, 60, 62, Bontrager Elite Aero VR-CF, alloy, 31.8mm, invisible cable routing, 93mm reach, 123mm drop, 44cm width |
| Saddle | Bontrager Aeolus Comp, steel rails, 145mm width |
| Seatpost | Size: 47, 50, 52, 54, 56, Madone aero carbon internal seatmast cap, integrated light mount, 5mm offset, short length; Size: 58, 60, 62, Madone aero carbon internal seatmast cap, integrated light mount, 5mm offset, tall length Type: Rigid |
| Rear Derailleur | Shimano Ultegra R8000, short cage, 30T max cog |
|---|---|
| Front Derailleur | Shimano Ultegra R8000, braze-on |
| Crank | Size: 47, Shimano Ultegra R8000, 50/34 (compact), 165mm length; Size: 50, 52, Shimano Ultegra R8000, 50/34 (compact), 170mm length; Size: 54, 56, Shimano Ultegra R8000, 50/34 (compact), 172.5mm length; Size: 58, 60, 62, Shimano Ultegra R8000, 50/34 (compact), 175mm length |
| Shifters | Shimano Ultegra R8020, 11 speed |
| Cassette | Shimano Ultegra R8000, 11-30, 11 speed |
| Chain | Shimano Ultegra HG701, 11 speed |
| Brakes | Hydraulic Disc Type: Hydraulic Disc |
| Rims | Front: Bontrager Aeolus Comp, Tubeless Ready, 18mm rim width, 100x12mm thru axle, Rear: Bontrager Aeolus Comp Disc, Tubeless Ready, 18mm rim width, 142x12mm thru axle |
|---|---|
| Tires | Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25mm |
| Disc Rotors | Shimano MT800, centerlock, 160mm |
