2022 Trek Émonda SLR 9

A carbon frame race bike with ultra high-end components and hydraulic disc brakes, priced near the high end of the Émonda model range. Compare the full range

View on trekbikes.com

2022 Trek Émonda SLR 9
MSRP$12,549
Weight14.8 lbs
FrameCarbon
ForkCarbon
Wheels700c Carbon
Tire Clearance28c
Drivetrain2 × 12 Electronic
GroupsetDura-Ace Di2
BrakesHydraulic Disc
Add to Comparison
Where to Buy
Similar Bikes Available Now
Compare With Similar Bikes

Gearing

2 × 12 — 24 speed

Émonda SLR 9

41 mph

Similar Bikes

40 mph

The Émonda SLR 9 is easier to ride up hills than similar bikes.

Similar bikes won‘t keep up with the Émonda SLR 9 while riding downhill or sprinting.


Estimated Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more. Learn more

Spec level →$0$2,000$4,000$6,000$8,000$10,000$12,000
This bike
Other race bikes

Reviews

April 2022

road.cc
Trek Émonda SL 5 Disc

The Émonda is a classic all-rounder, fun, fast and stiff, although this model isn't the lightest

Read Full Review

August 2020

Cycling Weekly
Trek Émonda SL6 Pro

Trek's latest GC/climbing bike has undergone an aero transformation, but has it helped?

Read Full Review

June 2020

Bicycling
Aero Tuning Makes the New Trek Émonda Faster Than Ever

Already one of the fiercest climbing bikes available, the new Émonda is even faster thanks to a dose of aero.

Read Full Review

June 2020

Bikerumor
Trek Émonda goes aero, gains T47 BB, Aeolus RSL integrated bar-stem & sub-700g frame!

Have you seen Bontrager’s new Aeolus carbon wheel lineup? Spanning the gap between budget and race ready, the aerodynamic hoops are the perfect complement to another new Trek product launching today – the all new Émonda. Fans of super light, efficient climbing bikes needn’t worry. The Émonda is still as light as ever, but now […]

Read Full Review

June 2020

Gran Fondo
2021 Trek Émonda SLR 9 eTap road bike first ride review – An aerodynamic climber

With Trek's completely revised 2021 Émonda SLR 9 eTap, the American brand's lightest frame goes into the 3rd generation. Have Trek managed to design an aerodynamic climbing specialist that performs just as well on flat terrain? How does it compare to the Madone? Our first ride review includes everything you need to know about the brand new bike!

Read Full Review

March 2019

Canadian Cycling Magazine
The alloy Trek Émonda ALR disc review

Sleek looking and smart riding sparkling purple frame makes a strong case to build a dream machine with an aluminium frameset

Read Full Review


Geometry

Sizing
47cm

4'11" – 5'3"

50cm

5'1" – 5'5"

52cm

5'3" – 5'7"

54cm

5'5" – 5'9"

56cm

5'8" – 6'0"

58cm

5'10" – 6'2"

60cm

6'0" – 6'4"

62cm

6'2" – 6'5"


Specs
Build
Frame

Ultralight 800 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle

BB StandardT47, threaded

Tire Clearance28c

ColorsMatte Deep Smoke; Amethyst; Dark Prismatic / Trek Black; Navy Carbon Smoke / Viper Red; Navy Carbon Smoke / Blue; Radioactive Coral to Yellow Fade

Fork

Emonda SLR full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle

Bottom Bracket

Praxis, T47 threaded, internal bearing

Handlebar

Size: 47, 50, Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 38cm width, 80mm stem length; Size: 52, Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 40cm width, 90mm stem length; Size: 54, Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 90mm stem length; Size: 56, Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 100mm stem length; Size: 58, Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 110mm stem length; Size: 60, 62, Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 44cm width, 110mm stem length

Saddle

Size: 47, 50, 52, Bontrager Aeolus P2 Pro, carbon rails, 155mm width; Size: 54, 56, 58, 60, 62, Bontrager Aeolus Pro, carbon rails, 145mm width

Seatpost

Size: 47, 50, 52, 54, Bontrager carbon seatmast cap, 20mm offset, short length; Size: 56, 58, 60, 62, Bontrager carbon seatmast cap, 20mm offset, tall length

Groupset
Rear Derailleur

Shimano Dura-Ace R9250 Di2

Front Derailleur

Shimano Dura-Ace R9250 Di2, braze-on, down swing

Crank

Size: 47, Shimano Dura-Ace R9200, 52/36, 165mm length; Size: 50, 52, Shimano Dura-Ace R9200, 52/36, 170mm length; Size: 54, 56, 58, Shimano Dura-Ace R9200, 52/36, 172.5mm length; Size: 60, 62, Shimano Dura-Ace R9200, 52/36, 175mm length

Shifters

Shimano Dura-Ace R9270 Di2, 12 speed

Cassette

Shimano Dura-Ace R9200, 11-30, 12 speed

Chain

Shimano Dura-Ace/XTR M9100, 12 speed

Brakes

hydraulicDisc

Wheels
Rims

Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle

Rear Hub

Bontrager Aeolus, OCLV Carbon, Tubeless Ready, Shimano 11/12 speed freehub, 142x12mm thru axle

Tires

Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25c

Disk Rotors

Shimano MT900, centerlock, 160mm
