2022 Trek Émonda ALR 4

An aluminum frame race bike with mid-range components and hydraulic disc brakes, priced near the low end of the Émonda model range. Compare the full range

View on trekbikes.com

2022 Trek Émonda ALR 4
MSRP€1,949 (about $2,377)
Weight20.6 lbs
Framealuminum
ForkCarbon
Wheels700c
Tire Clearance28c
Drivetrain2 × 10
GroupsetTiagra
BrakesHydraulic Disc
Add to Comparison
Where to Buy
Similar Bikes Available Now
Compare With Similar Bikes

Gearing

2 × 10 — 20 speed

Émonda ALR 4

36 mph

Similar Bikes

40 mph

The Émonda ALR 4 is geared about the same as similar bikes for riding up hills.

The Émonda ALR 4 won‘t keep up with similar bikes while riding downhill or sprinting.


Estimated Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more. Learn more

Spec level →$0$500$1,000$1,500$2,000
This bike
Other race bikes

Reviews

April 2022

road.cc
Trek Émonda SL 5 Disc

The Émonda is a classic all-rounder, fun, fast and stiff, although this model isn't the lightest

Read Full Review

August 2020

Cycling Weekly
Trek Émonda SL6 Pro

Trek's latest GC/climbing bike has undergone an aero transformation, but has it helped?

Read Full Review

June 2020

Bicycling
Aero Tuning Makes the New Trek Émonda Faster Than Ever

Already one of the fiercest climbing bikes available, the new Émonda is even faster thanks to a dose of aero.

Read Full Review

June 2020

Bikerumor
Trek Émonda goes aero, gains T47 BB, Aeolus RSL integrated bar-stem & sub-700g frame!

Have you seen Bontrager’s new Aeolus carbon wheel lineup? Spanning the gap between budget and race ready, the aerodynamic hoops are the perfect complement to another new Trek product launching today – the all new Émonda. Fans of super light, efficient climbing bikes needn’t worry. The Émonda is still as light as ever, but now […]

Read Full Review

June 2020

Gran Fondo
2021 Trek Émonda SLR 9 eTap road bike first ride review – An aerodynamic climber

With Trek's completely revised 2021 Émonda SLR 9 eTap, the American brand's lightest frame goes into the 3rd generation. Have Trek managed to design an aerodynamic climbing specialist that performs just as well on flat terrain? How does it compare to the Madone? Our first ride review includes everything you need to know about the brand new bike!

Read Full Review

March 2019

Canadian Cycling Magazine
The alloy Trek Émonda ALR disc review

Sleek looking and smart riding sparkling purple frame makes a strong case to build a dream machine with an aluminium frameset

Read Full Review


Geometry

Specs
Build
Frame

Ultralight 300 Series Alpha Aluminium, Invisible Weld technology, tapered head tube, Control Freak internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle

BB StandardBB86/BB92, 86.5mm, press-fit

Tire Clearance28c

ColorsLithium Grey; Radioactive Red to Marigold Fade

Bottom Bracket

Shimano BB71, 86.5 mm, PressFit

Stem

Size: 47, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length; Size: 50, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length; Size: 52, 54, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length; Size: 56, 58, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length; Size: 60, 62, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length

Handlebar

Size: 47, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 38 cm width; Size: 50, 52, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width; Size: 54, 56, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width; Size: 58, 60, 62, 64, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width

Saddle

Bontrager Montrose Comp, steel rails, 138 mm width

Seatpost

Size: 47, Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length; Size: 50, 52, 54, 56, 58, 60, 62, 64, Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length

Groupset
Rear Derailleur

Shimano Tiagra 4700, long cage, 34T max cog

Front Derailleur

Shimano Tiagra 4700, braze-on

Crank

Size: 47, 50, 52, Shimano Tiagra 4700, 50/34, 170 mm length; Size: 54, 56, Shimano Tiagra 4700, 50/34, 172.5 mm length; Size: 58, 60, 62, 64, Shimano Tiagra 4700, 50/34, 175 mm length

Shifters

Shimano Tiagra R4725, short-reach lever, 10-speed

Cassette

Shimano Tiagra HG500, 12-28, 10-speed

Chain

Shimano Tiagra HG54, 10-speed

Brakes

Shimano Tiagra hydraulic disc

Wheels
Rims

Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21 mm width, Presta valve

Front Hub

Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle

Rear Hub

Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle

Tires

Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x 25 c

Disk Rotors

Shimano SM-RT70, CenterLock, 160 mm
