For This Bike
4'11" – 5'3"
5'1" – 5'5"
5'3" – 5'7"
5'5" – 5'9"
5'8" – 6'0"
5'10" – 6'2"
6'0" – 6'4"
6'2" – 6'5"
Sep 2023
Now on its fourth iteration, the Trek Domane AL is packed with updates, a lighter frame, and room for larger tires.
Jan 2023 · Josh Croxton
Fewer Isospeeds means it's a little less comfortable, but the new Domane SLR 9 is fast, fun, and ready for an adventure
Easy to use storage compartment with neat & organising tool wrap
Simplified Isospeed vibration damping
38mm tyre clearance
Power meter included
Neat, low-maintenance integrated cockpit
Oh boy is it pricey
I would hope for top-spec tyres at this price
Oct 2022 · James Spender
The Domane is a tremendously smooth bike thanks to Trek’s IsoSpeed rear damping system and high volume, 32mm tubeless tyres
Comfort
Handling
Descending
Over-engineered
Sep 2022
The new Domane is everything great about the old bike, plus lighter and quicker.
Sep 2022 · William Tracy
Trek has simplified its endurance frame and put it on a diet for a more enjoyable ride.
May 2022 · Warren Rossiter
Endurance smoothy goes wireless
Impossibly smooth riding
Handles with ease
Very versatile
Carrying a bit more weight than its rivals
Apr 2022 · Ben Delaney
Major changes include elimination of the seat mast, front IsoSpeed and adjustment on rear IsoSpeed.
Jul 2021 · Mat Brett
Smooth-riding endurance bike with loads of tyre space and masses of versatility
Smooth ride
Space for big tyres
Internal storage
Not especially light
| Frame | 500 Series OCLV Carbon, front & rear IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, DuoTrap S compatible, fender mounts, flat mount disc, 142x12mm thru axle BB Standard: T47, Threaded Tire Clearance: 38c Colors: Crimson / Trek Black; Satin Dark Aquatic / Satin Trek Black |
|---|---|
| Fork | Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
| Bottom Bracket | SRAM DUB, T47 threaded, internal bearing |
| Stem | Size: 47, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: 50, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 52, 54, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 56, 58, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: 60, 62, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 110mm length |
| Handlebar | Size: 47, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 36cm width; Size: 50, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width; Size: 52, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width; Size: 54, 56, Bontrager Elite IsoZone VR-CF, alloy, 31.8mm, internal Di2 routing, 93mm reach, 123mm drop, 42cm width; Size: 58, 60, 62, Bontrager Elite IsoZone VR-CF, alloy, 31.8mm, internal Di2 routing, 93mm reach, 123mm drop, 44cm width |
| Saddle | Size: 47, 50, 52, Bontrager P3 Verse Comp, steel rails, 155mm width; Size: 54, 56, 58, 60, 62, Bontrager P3 Verse Comp, steel rails, 145mm width |
| Seatpost | Size: 47, 50, 52, 54, 56, Bontrager carbon internal seatmast cap, integrated light mount, 20mm offset, short length; Size: 58, 60, 62, Bontrager carbon internal seatmast cap, integrated light mount, 20mm offset, tall length Type: Rigid |
| Rear Derailleur | SRAM Rival eTap AXS |
|---|---|
| Front Derailleur | SRAM Rival eTap AXS, braze-on |
| Crank | Size: 47, SRAM Rival, 46/33, DUB, 165mm length; Size: 50, 52, SRAM Rival, 46/33, DUB, 170mm length; Size: 54, 56, SRAM Rival, 46/33, DUB, 172.5mm length; Size: 58, 60, 62, SRAM Rival, 46/33, DUB, 175mm length |
| Shifters | SRAM Rival eTap AXS, 12 speed |
| Cassette | SRAM XG-1250, 10-36, 12 speed |
| Chain | SRAM Rival, 12 speed |
| Brakes | Hydraulic Disc Type: Hydraulic Disc |
| Rims | Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle |
|---|---|
| Front Hub | Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle |
| Rear Hub | Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, SRAM XD-R freehub, 142x12 thru axle |
| Tires | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32c |
| Disc Rotors | SRAM Paceline, rounded, centerlock, 160mm |
Last updated March 18
Not listed for 31 days
