2022 Trek
Checkpoint SLR 9 eTap
A carbon frame gravel bike with ultra high-end components and hydraulic disc brakes.
Compare the full range
| MSRP | $12,049 |
|---|---|
| Weight | 17.9 lbs |
| Frame | Carbon |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Carbon |
| Drivetrain | 1 × 12 Electronic |
| Groupset | RED XPLR eTap, RED AXS |
| Power Meter | Red AXS |
| Brakes | Hydraulic Disc |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Checkpoint model range
View Comparison5'1" – 5'5"
5'3" – 5'7"
5'5" – 5'9"
5'8" – 6'0"
5'10" – 6'2"
6'0" – 6'4"
- 5'7", size 54, Fits large
- 5'10", size LG, Just right
- 5'9", size 52cm, Just right
Jun 2023 · Calvin Zajac
A comfortable all-purpose weapon, and a premium price –which boxes can the Trek Checkpoint SLR 9 eTap tick? We putit through the wringer to find out!
IsoSpeed system is inconspicuous and functional, providing added comfort at the rear
Versatile
Storage compartment in the down tube
Round, less ergonomic handlebars
Bontrager GR1 Team Issue TR tires lack grip in damp conditions and tend to bounce
Unbalanced level of compliance between the front and rear
Oct 2022 · Mat Brett
Get all the details of this fiery red gravel/adventure bike with Trek’s gravel-smoothing IsoSpeed
Sep 2022 · Josh Ross
The Trek Checkpoint is the only bike you need to take you on every adventure
SRAM Rival AXS is the perfect groupset for an all-arounder
Mud-guard mounts
Mounting points for every bag you can think of
Non-proprietary seat-post provides options
Internal storage is convenient
Downtube protection eases worry
Threaded bottom bracket
Ideal all-around gearing
Short stem for added stability means handlebar/knee interference
Lacks included protection for the chain stay
Detail behind the fork steerer collects water and is difficult to clean
Sep 2022 · Steve Williams
Trek's updated aluminum Checkpoint is a surefooted, confidence-inspiring ride that's perfect for ruined back lanes, byways and well-laden travels
Stable and predictable
Comfortable
Great shifting and brakes
Gearing a bit tall for the weight
Could use a dropper post
Jul 2022 · Ben Delaney
Trek’s versatile gravel bike offers progressive geometry, hidden storage, a racy but comfortable ride, and a sizeable price tag
Comfortable ride
Progressive geometry
Smart but unfussy mounts
Conventional bar and stem
Costs as much as a small car
No power meter
Heavier than much of the competition
May 2022 · Jack Luke
A highly versatile gravel bike that's comfortable and decent value too
Notably comfortable ride
Very versatile
Inelegant seat-clamp design
Occasionally rattly
Sep 2021
Updated geometry and differentiated models for speed, adventure, and all purpose riding
Sep 2021 · Matthew Pioro
Also, a tour of the revamped Trek Checkpoint lineup of bikes and Adventure bags for mixed-surface adventures
| Frame | 700 Series OCLV Carbon, IsoSpeed, downtube storage door, internal routing, Ride Tuned seat mast, chain keeper, T47 BB, fender mounts, integrated frame bag mounts, flat mount disc, 142x12mm thru axle BB Standard: T47, Threaded Tire Clearance: 45c Colors: Matte Deep Smoke / Gloss Olive Grey; Era White / Emerald Iris; Marigold / Nautical Navy; Radioactive Coral |
|---|---|
| Fork | Checkpoint carbon, tapered carbon steerer, fender mounts, flat mount disc, 12x100mm thru axle |
| Bottom Bracket | SRAM DUB, T47 threaded, internal bearing |
| Stem | Size: 49, Bontrager RSL Carbon, 31.8mm clamp, 7 degree, 70mm length; Size: 52, 54, Bontrager RSL Carbon, 31.8mm clamp, 7 degree, 80mm length; Size: 56, 58, Bontrager RSL Carbon, 31.8mm clamp, 7 degree, 90mm length; Size: 61, Bontrager RSL Carbon, 31.8mm clamp, 7 degree, 100mm length |
| Handlebar | Size: 49, Bontrager Pro IsoCore VR-SF, 38cm; Size: 52, Bontrager Pro IsoCore VR-SF, 40cm; Size: 54, 56, Bontrager Pro IsoCore VR-SF, 42cm; Size: 58, 61, Bontrager Pro IsoCore VR-SF, 44cm |
| Saddle | Size: 49, 52, Bontrager P3 Verse Pro, carbon rails, 155mm width; Size: 54, 56, 58, 61, Bontrager P3 Verse Pro, carbon rails, 145mm width |
| Seatpost | Size: 49, 52, 54, 56, Bontrager carbon seatmast cap, 5mm offset, short length; Size: 58, 61, Bontrager carbon seatmast cap, 5mm offset, tall length Type: Rigid |
| Rear Derailleur | SRAM RED XPLR eTap AXS, 44T max cog |
|---|---|
| Crank | Size: 49, SRAM RED AXS Power Meter, 40T, DUB, 165mm length; Size: 52, SRAM RED AXS Power Meter, 40T, DUB, 170mm length; Size: 54, 56, SRAM RED AXS Power Meter, 40T, DUB, 172.5mm length; Size: 58, 61, SRAM RED AXS Power Meter, 40T, DUB, 175mm length |
| Power Meter | Size: 49, SRAM RED AXS Power Meter, 40T, DUB, 165mm length; Size: 52, SRAM RED AXS Power Meter, 40T, DUB, 170mm length; Size: 54, 56, SRAM RED AXS Power Meter, 40T, DUB, 172.5mm length; Size: 58, 61, SRAM RED AXS Power Meter, 40T, DUB, 175mm length |
| Shifters | SRAM RED eTap AXS, 12 speed |
| Cassette | SRAM XG-1271, 10-44, 12 speed |
| Chain | SRAM RED D1, 12 speed |
| Brakes | Hydraulic Disc Type: Hydraulic Disc |
| Rims | Front: Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle, Rear: Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37mm rim depth, 142x12mm thru axle |
|---|---|
| Tires | Bontrager GR1 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 120 tpi, 700x40c |
| Disc Rotors | SRAM CenterLine X, centerlock, round edge, 160mm |
