2021 Trek
Madone SLR 9
A carbon frame aero bike with ultra high-end components and hydraulic disc brakes.
Manufacturer Price
$12,499| Weight | 17.2 lbs |
|---|---|
| Frame | Carbon |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Carbon |
| Drivetrain | 2 × 11 Electronic |
| Groupset | Dura-Ace Di2 |
| Power Meter | Dura-Ace |
| Brakes | Hydraulic Disc |
For This Bike
4'11" – 5'3"
5'1" – 5'5"
5'3" – 5'7"
5'5" – 5'9"
5'8" – 6'0"
5'10" – 6'2"
6'0" – 6'4"
6'2" – 6'5"
Dec 2022 · Sam Challis
The new Madone is leaner, meaner and wickedly quick
Very fast ride feel
Smart componentry design
Light weight
Comfort
Price
Narrow bars take some getting used to
Vulnerable in gusty conditions
Jun 2022 · Matt Hansen
The frame features striking new tube shapes and radical rear triangle
Mar 2022 · Ben Delaney
The Greek god of the winds invoked at three points on the sprinter's bike.
Jul 2020
What’s better than Trek’s Madone SLR? How about a Madone SLR that’s lighter? Or one with a different bottom bracket? If either of those sound good to you, then you’ll want to check out the 2021 Madone SLR. The SLR addition to the Madone name gives the indication that this isn’t your average Trek. In […]
Dec 2019 · Symon Lewis
Cycling Weekly has shown that the Trek Madone is one of the fastest aero bikes available today, but has the update with discs made it even better? I certainly think so
Ride quality
Performance
Comfort
Stiffness
Weight
Jun 2019 · David Arthur @davearthur
Seriously fast aero race bike with great handling, but not the smoothest and not the ultimate spec it should be
Mar 2019 · Warren Rossiter
Winner of best superbike in our annual Bike of the Year awards is the latest evolution of Trek’s flagship aero bike
Groundbreaking comfort, stunning handling and seriously rapid
Five-figure price tag
Nov 2018 · Manuel Buck
Das Beste. The Best. Le Meilleur. The latest generation of the Trek Madone SLR 9 Disc promises to be even faster, more aerodynamic and lighter.
| Frame | 800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, T47 BB, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle BB Standard: T47, Threaded Tire Clearance: 28c Colors: Navy Carbon Smoke / Viper Red; Navy Carbon Smoke / Blue; Matte Onyx Carbon |
|---|---|
| Fork | Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat-mount disc, carbon dropouts, 12x100 mm thru axle |
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Stem | Size: 47, 50, 52, 54, Trek Madone aero, invisible cable routing, 7-degree, 90 mm length; Size: 56, 58, Trek Madone aero, invisible cable routing, 7-degree, 100 mm length; Size: 60, 62, Trek Madone aero, invisible cable routing, 7-degree, 110 mm length |
| Handlebar | Size: 47, Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93 mm reach, 123 mm drop, 38 cm width; Size: 50, 52, Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93 mm reach, 123 mm drop, 40 cm width; Size: 54, 56, Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93 mm reach, 123 mm drop, 42 cm width; Size: 58, 60, 62, Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93 mm reach, 123 mm drop, 44 cm width |
| Saddle | Bontrager Aeolus Pro, carbon rails, 145 mm width |
| Seatpost | Size: 47, 50, 52, 54, 56, Madone aero carbon internal seat mast cap, integrated light mount, 25 mm offset, short length; Size: 58, 60, 62, Madone aero carbon internal seat mast cap, integrated light mount, 25 mm offset, tall length Type: Rigid |
| Rear Derailleur | Shimano Dura-Ace Di2 R9150, short cage, 30T max cog |
|---|---|
| Front Derailleur | Shimano Dura-Ace Di2 R9150, braze-on |
| Crank | Size: 47, Shimano Dura-Ace R9100-P Power Meter, 52/36, 165 mm length; Size: 50, 52, Shimano Dura-Ace R9100-P Power Meter, 52/36, 170 mm length; Size: 54, 56, Shimano Dura-Ace R9100-P Power Meter, 52/36, 172.5 mm length; Size: 58, 60, 62, Shimano Dura-Ace R9100-P Power Meter, 52/36, 175 mm length |
| Power Meter | Size: 47, Shimano Dura-Ace R9100-P Power Meter, 52/36, 165 mm length; Size: 50, 52, Shimano Dura-Ace R9100-P Power Meter, 52/36, 170 mm length; Size: 54, 56, Shimano Dura-Ace R9100-P Power Meter, 52/36, 172.5 mm length; Size: 58, 60, 62, Shimano Dura-Ace R9100-P Power Meter, 52/36, 175 mm length |
| Shifters | Shimano Dura-Ace Di2 R9170, 11-speed |
| Cassette | Shimano Dura-Ace R9100, 11-30, 11-speed |
| Chain | Shimano Dura-Ace 9000, 11-speed |
| Brakes | Shimano Dura-Ace hydraulic disc Type: Hydraulic Disc |
| Rims | Front: Bontrager Aeolus XXX 4, OCLV Carbon, Tubeless Ready, 21 mm rim width, 47mm rim depth, 100x12 mm thru axle, Rear: Bontrager Aeolus XXX 4, OCLV Carbon, Tubeless Ready, 21 mm rim width, 47 mm rim depth, 142x12 mm thru axle |
|---|---|
| Tires | Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700x25 c |
| Disc Rotors | Shimano RT900, 160 mm, CenterLock |
