2021 Trek
Émonda ALR 5
An aluminum frame race bike with upper mid-range components and hydraulic disc brakes.
Manufacturer Price
$2,099| Weight | 19.9 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 11 |
| Groupset | 105 |
| Brakes | Hydraulic Disc |
For This Bike
4'11" – 5'3"
5'1" – 5'5"
5'3" – 5'7"
5'5" – 5'9"
5'8" – 6'0"
5'10" – 6'2"
6'0" – 6'4"
6'2" – 6'5"
Oct 2022 · Warren Rossiter
A climb-friendly bike with aero styling
Snappy handling
Fast to respond through the pedals
Power meter included in a fine package
Faster tyres would enhance its ride further
Apr 2022 · Stu Kerton
The Émonda is a classic all-rounder, fun, fast and stiff, although this model isn't the lightest
Internal cable routing gives a very clean look
A great all-rounder
Good finishing kit
Not exactly light
Aug 2020 · James Bracey
Trek's latest GC/climbing bike has undergone an aero transformation, but has it helped?
Efficient power transfer
Excellent handling prowess
Compliant ride
New SL frame has lost some of the excitement of the existing Émonda
Heavy for a 'climbing' bike
Jul 2020 · Dan Cavallari
OCLV 800 launched with Trek's feathery Émonda, but now the brand's flagship aero bike gets this lighter, stiffer carbon — along with a T47 BB.
Jun 2020
Have you seen Bontrager’s new Aeolus carbon wheel lineup? Spanning the gap between budget and race ready, the aerodynamic hoops are the perfect complement to another new Trek product launching today – the all new Émonda. Fans of super light, efficient climbing bikes needn’t worry. The Émonda is still as light as ever, but now […]
Mar 2019 · Philippe Tremblay
Sleek looking and smart riding sparkling purple frame makes a strong case to build a dream machine with an aluminium frameset
Aug 2018
A smooth and stylee aluminum road bike that hauls ass at a great price
Aug 2018 · Benjamin Topf
The Trek Émonda ALR 6 is the highest-quality aluminium racer in Trek’s portfolio, but can the performance keep up with the superb looks?
| Frame | Ultralight 300 Series Alpha Aluminum, Invisible Weld technology, tapered head tube, Control Freak internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle BB Standard: BB86/BB92, 86.5mm, Press Fit Tire Clearance: 28c Colors: Purple Abyss; Slate to Trek Black Fade; Matte Gravel / Gloss Quicksilver; Purple Flip |
|---|---|
| Fork | Emonda SL full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle |
| Bottom Bracket | Shimano BB71, 86.5mm, PressFit |
| Headset | FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom |
| Stem | Size: 47, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: 50, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 52, 54, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 56, 58, Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 100mm length; Size: 56, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: 60, 62, Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 110mm length |
| Handlebar | Size: 47, 50, 52, Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 40cm width; Size: 54, 56, Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 42cm width; Size: 58, 60, 62, Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 44cm width |
| Saddle | Size: 47, 50, 52, 54, 56, 58, 60, 62, Bontrager Montrose Comp, steel rails, 138mm width; Size: 47, 50, 52, Bontrager P3 Verse Comp, steel rails, 155mm width; Size: 54, 56, Bontrager P3 Verse Comp, steel rails, 145mm width |
| Seatpost | Bontrager carbon, 27.2mm, 8mm offset, 330mm length Type: Rigid |
| Rear Derailleur | Shimano 105 R7000, short cage, 30T max cog |
|---|---|
| Front Derailleur | Shimano 105 R7000, braze-on |
| Crank | Size: 47, 50, 52, Shimano 105 R7000, 50/34 (compact), 170mm length; Size: 54, 56, Shimano 105 R7000, 50/34 (compact), 172.5mm length; Size: 58, 60, 62, Shimano 105 R7000, 50/34 (compact), 175mm length |
| Shifters | Shimano 105 R7020, 11 speed |
| Cassette | Shimano 105 R7000, 11-28,11 speed |
| Chain | Shimano 105 HG601, 11 speed |
| Brakes | Shimano 105 hydraulic disc, flat mount Type: Hydraulic Disc |
| Rims | Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21mm width, presta valve |
|---|---|
| Spokes | 14g stainless steel |
| Front Hub | Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle |
| Rear Hub | Bontrager alloy, sealed bearing, centerlock, Shimano 11-speed freehub, 142x12mm thru axle |
| Tires | Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x25c |
| Disc Rotors | Shimano SM-RT70, centerlock, 160mm |
