2020 Trek
Madone SL 6 Disc
A carbon frame aero bike with ultra high-end components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
$4,699| Weight | 19.0 lbs |
|---|---|
| Frame | Carbon |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 11 |
| Groupset | Ultegra |
| Brakes | Hydraulic Disc |
For This Bike
5'1" – 5'5"
5'3" – 5'7"
5'5" – 5'9"
5'7" – 6'0"
5'10" – 6'2"
6'0" – 6'4"
6'2" – 6'6"
Aug 2021
Trek announced a few updates to its world-class race machine, the Madone SL is swapping to a more widely appreciated BB47 bottom bracket
Mar 2020 · Warren Rossiter
Trek with the unique design of the Madone and its IsoSpeed back-end means it doesn’t have to drop the stays for comfort or minimise the size of the stays for flex because IsoSpeed isolates the seat tube from the stays and top tube.. .
Awesome ride
Racy handling
A bit weighty
Dec 2019 · Symon Lewis
Cycling Weekly has shown that the Trek Madone is one of the fastest aero bikes available today, but has the update with discs made it even better? I certainly think so
Ride quality
Performance
Comfort
Stiffness
Weight
Aug 2019 · Stu Bowers
Trek proves hands down that disc brakes, true-aero race geometry, light weight and sublime comfort no longer need to be conflicting
Incredibly comfy rear end that’s adjustable to suit rider preference
Super fast
With handling to back it up
You may need to sell a kidney or remortgage the house to afford one
Jun 2019 · David Arthur @davearthur
Seriously fast aero race bike with great handling, but not the smoothest and not the ultimate spec it should be
Nov 2018 · Manuel Buck
Das Beste. The Best. Le Meilleur. The latest generation of the Trek Madone SLR 9 Disc promises to be even faster, more aerodynamic and lighter.
Jul 2018 · Dan Cavallari
Trek has fine-tuned its IsoSpeed Decoupler, improved the fit, and added disc brakes, making this edition of the Madone even better.
Jul 2018
It might look the same on the outside, but underneath it's an all new Madone
| Frame | 500 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, flat mount disc, Duo Trap S compatible, 142x12mm thru axle BB Standard: BB90, 90.5mm, Press Fit |
|---|---|
| Fork | Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat mount disc, carbon dropouts, 12x100mm thru axle |
| Bottom Bracket | Trek BB90 |
| Stem | Size: 50, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 52, 54, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 56, 58, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: 60, 62, Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 110mm length |
| Handlebar | Size: 50, 52, Bontrager Elite Aero VR-CF, alloy, 31.8mm, invisible cable routing, 93mm reach, 123mm drop, 40cm width; Size: 54, 56, Bontrager Elite Aero VR-CF, alloy, 31.8mm, invisible cable routing, 93mm reach, 123mm drop, 42cm width; Size: 58, 60, 62, Bontrager Elite Aero VR-CF, alloy, 31.8mm, invisible cable routing, 93mm reach, 123mm drop, 44cm width |
| Saddle | Bontrager Aeolus Comp, steel rails, 145mm width |
| Seatpost | Size: 50, 52, 54, 56, Madone aero carbon internal seatmast cap, integrated light mount, 25mm offset, short length; Size: 58, 60, 62, Madone aero carbon internal seatmast cap, integrated light mount, 25mm offset, tall length Type: Rigid |
| Rear Derailleur | Shimano Ultegra R8000, short cage, 30T max cog |
|---|---|
| Front Derailleur | Shimano Ultegra R8000, braze-on |
| Crank | Size: 50, 52, Shimano Ultegra R8000, 50/34 (compact), 170mm length; Size: 54, 56, Shimano Ultegra R8000, 50/34 (compact), 172.5mm length; Size: 58, 60, 62, Shimano Ultegra R8000, 50/34 (compact), 175mm length |
| Shifters | Shimano Ultegra R8020, 11-speed |
| Cassette | Size: 50, 52, 54, 56, 58, 60, 62, Shimano Ultegra R8000, 11-28, 11 speed; Size: 50, 52, 54, 56, 58, 60, 62, Shimano Ultegra R8000, 11-30, 11 speed |
| Chain | Shimano Ultegra HG701, 11-speed |
| Brakes | Size: 50, 52, 54, 56, 58, 60, 62, Shimano Ultegra hydraulic disc, flat mount; Size: 50, 52, 54, 56, 58, 60, 62, Shimano Dura-Ace hydraulic disc, flat mount Type: Hydraulic Disc |
| Rims | Front: Bontrager Aeolus Comp, Tubeless Ready, 18mm rim width, 100x12mm thru axle, Rear: Bontrager Aeolus Comp Disc, Tubeless Ready, 18mm rim width, 142x12mm thru axle |
|---|---|
| Tires | Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25c |
| Disc Rotors | Shimano RT800, 160mm, centerlock |
