2020 Trek

Fuel EX 5

A 27.5″ / 29″ aluminum frame full suspension trail bike with upper mid-range components.
Compare the full range

MSRP$2,099
Weight33.1 lbs
FrameAluminum
SuspensionFull, 130 / 140mm
ForkRockShox Recon Silver RL
ShockRockShox Deluxe Select+
Wheels27.5″ / 29″ Aluminum
Drivetrain1 × 10
GroupsetDeore, Race Face
BrakesHydraulic Disc
SeatpostDropper
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
Fuel EX 5
Other Trail bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

24 mph

Fuel EX 5

26 mph

Similar Bikes

Highest gear

(descending)

Reviews
Gran Fondo Magazine
Trek Fuel EX 9.9 XTR Project One in bikepacking review

Oct 2020 · Benjamin Topf

The Trek Fuel EX 9.9 is an absolute classic in the trail bike segment. Could it also be the perfect bike for the next bikepacking adventure with its modern geometry and spare parts compartment in the down tube? We put the Fuel EX to the test.

Highs
  • Maximum fun on the descents

  • Intuitive and good-natured handling

  • Storage compartment in the down tube for tools or snacks

Lows
  • Too sluggish on easy terrain

  • Too much bike for long straights

  • Chain slap

Read Review

Freehub
Bike Review | 2020 Trek Fuel EX 9.9

Jun 2020 · Spencer Johnson

As warmer temperatures hit the Pacific Northwest and the dirt starts to dry, I’m always eager to get out on some long rides with some big climbs. Naturally, when this Trek Fuel EX 9.9 showed up at the Freehub office, I knew it was time to put the nimble beast through its paces. I challenged myself to a 60-mile sufferfest on some of Bellingham, Washington’s toughest climbs and descents. It definitely didn’t let me down. Climbing on this bike was a joy. Trek equipped the 9.9 model with its proprietary RE:aktiv shock with a three-position damper, which I left wide open for the entire ride. The rear suspension had an overwhelmingly supportive feel while pedaling out of the saddle, yet as soon as I hit a bump it dived deeper into the travel, keeping the rear wheel firmly planted and providing excellent traction. The geometry is modern and balanced, with a long reach and a sensible 76-degree seat angle. On the descents, the bike inspired confidence, thanks to its long wheelbase and bottomless-feeling suspension. My confidence was further enhanced by the reliable stopping power of the Shimano XT brakes. As a 200-pound rider, I couldn’t have appreciated the ultra-powerful XT brakes and the 203-millimeter front rotor more—especially while bombing down some of Bellingham’s scariest double-black trails.

Read Review

BikeRadar
Trek Fuel EX 9.7 review

Apr 2020 · Tom Marvin

A classic trail bike, with a fun and engaging ride built around a solid frame

Highs
  • A solid feeling frame backed up by a ride quality that encourages you to pop and play around

Lows
  • The long Shimano brake levers kill the feel, while the supple rear suspension shows up the budget fork

Read Review

Flow Mountain Bike
9 Lessons We've Learned About Our 2020 Trek Fuel EX Test Bike

Apr 2020

After six months of testing, it's time to the deliver the review of our 2020 Trek Fuel EX 9.8 long-term test bike. Here we take a closer look at some of the other parts we've changed and the problems we've encountered, and discuss exactly what this 130mm travel trail bike does best.

Highs
  • Hugely capable for a 130mm travel trail bike

  • The stiff & responsive chassis

  • Supremely balanced & versatile handling

  • The suspension is so plush and well controlled

  • Improved pedal efficiency and support

  • Lifetime frame & carbon wheel warranty

Lows
  • Poor-fitting downtube trapdoor

  • The stock Bontrager dropper post is sluggish and sloppy

  • Carbon wheels are quite harsh

Read Review

Outdoor Gear Lab
Trek Fuel EX 5

Jan 2020 · Jeremy Benson

Trek recently redesigned their popular Fuel EX mid-travel trail bikes for the 2020 model year. The updated geometry brings this bike in line with modern...

Highs
  • Supple rear suspension

  • Versatile

  • Fun on a wide range of terrain

  • Affordable

Lows
  • Moderately heavy

  • Short dropper post

  • Frame sizing runs a little small

Read Review

BIKE Magazine
First Ride: 2020 Trek Fuel EX 9.9

Aug 2019

This is not what it looks like. Even though this new Fuel EX has a Fox 36, it doesn’t mean it has shed its trail-bike past for an enduro-bike future. Even

Read Review

Enduro Mountainbike Magazine
First ride review: the new Trek Fuel EX 9.9 2020 – longer, faster and even better?

Aug 2019 · Robin Schmitt

First ride review of the new Trek Fuel EX 9.9 2020 – details, weight, pricing and highlights of the new bike here!

Read Review

Pinkbike
Review: Trek's All-New 2020 Fuel EX Trail Bike

Aug 2019 · Mike Levy

Trek's trail bike gets an all-new frame with tweaked suspension and fresh geometry, but where does sit compared to the competition?

Highs
  • Forgiving, deep feeling suspension

  • It's a wizard on technical climbs

  • New geometry increases capabilities

Lows
  • It might be too forgiving for some riders

  • You'll be using the pedal assist lever often

  • Trek could have gone further with the geometry

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Alpha Platinum Aluminum, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130mm travel

BB StandardBB86/BB92, Press Fit

Tire Clearance2.6"

Fork

Size: XS, S, RockShox Recon RL, Solo Air spring, Motion Control damper, tapered steerer, 46mm offset, Boost110, 15mm Maxle Stealth, 140mm travel; Size: S, M, ML, L, XL, XXL, RockShox Recon RL, Solo Air spring, Motion Control damper, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 140mm travel

Travel140mm

Spring TypeAir

Shock

Size: XS, S, RockShox Deluxe Select+, 210x52.5mm; Size: S, M, ML, L, XL, XXL, RockShox Deluxe Select+, 210x55mm

Travel130mm

Spring TypeAir

Bottom Bracket

Shimano MT500, 92mm, PressFit

Stem

Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 50mm length

Handlebar

Bontrager alloy, 31.8mm, 15mm rise, 750mm width

Saddle

Bontrager Arvada, steel rails, 138mm width

Seatpost

Size: XS, S, TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length; Size: M, ML, L, XL, XXL, TranzX JD-YSP18, 130mm travel, internal routing, 31.6mm, 425mm length

TypeDropper

Grips

Bontrager XR Trail Comp, nylon lock-on

Groupset
Rear Derailleur

Shimano Deore M6000, mid cage, 42T max cog

Crank

Size: XS, S, Race Face Ride, 30T steel ring, Boost (52mm chainline), 170mm length; Size: M, ML, L, XL, XXL, Race Face Ride, 30T steel ring, Boost (52mm chainline), 175mm length

Shifters

Shimano Deore M6000, 10 speed

Cassette

SunRace, 11-42, 10 speed

Chain

KMC X10, 10 speed

Brakes

Shimano hydraulic disc, MT201 lever, MT200 caliper

TypeHydraulic Disc

Wheels
Rims

Alex MD35, Tubeless Ready, 32-hole, 35mm width, presta valve

Front Hub

Formula DC-511, 6-bolt, Boost110, 15mm thru axle

Rear Hub

Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano 8/9/10 freehub, Boost148, 12mm thru axle

Tires

Size: XS, S, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60''; Size: S, M, ML, L, XL, XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60''

Disc Rotors

Shimano RT56, 180mm, 6-bolt

Rider Notes
