2020 Trek

Allant+ 7S

A 650b aluminum frame commuter e-bike with mid-range components and hydraulic disc brakes.
Compare the full range

MSRP$3,899
Weight54.1 lbs
FrameAluminum
SuspensionHardtail, 50mm
ForkSuntour MOBIE
Wheels650b Aluminum
Drivetrain1 × 9
GroupsetAlivio
MotorBosch 250W 75Nm mid-drive
BatteryBosch 500Wh
BrakesHydraulic Disc
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Insights
Sizing
MD

5'4" – 5'10"

LG

5'8" – 6'2"

XL

6'0" – 6'6"

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Reviews
Bikerumor
Review: Trek Allant+ 8S is a sharp urban commuter e-bike

Dec 2021 · Tyler Benedict

If you like to ride fast & want a snappy handling commuter e-bike for navigating the urban environment, the Trek Allant+ is worth a look.

Read Review

Electric Bike Review
Trek Allant+ 7 Review

Apr 2020

Price: $3599.00 | Model Year: 2020 | A great all-around electric bike that's capable on city streets and light trail, it replaces the Trek Dual Sport+ from earlier years. Proven Bosch Peformance Line CX motor with shift detection. The high-step frame has mounts for adding a second battery pack (Bosch Range Boost) to double capacity, but the step-thru does not

Observations
  • A great all-around electric bike that's capable on city streets and light trail, it replaces the Trek Dual Sport+ from earlier years. Proven Bosch Peformance Line CX motor with shift detection. The high-step frame has mounts for adding a second battery pack (Bosch Range Boost) to double capacity, but the step-thru does not

  • Durable and quiet plastic fenders, sleek and sturdy Racktime rear rack, bright integrated lights with side windows to maximize visual footprint, reflective tires and high-contrast paint accents keep you seen.

  • Excellent weight distribution, clean integrated battery pack with Trek RIB casing for easy handling (because it has a built-in handle). Powerful smooth 180mm hydraulic disc brakes. Highly adjustable coil spring suspension fork with lockout, preload, and rebound

  • The bike only comes in one color, but each frame type has three sizes for optimal fit. Trek has a vast network of dealers and is recognized as one of the "big three" ebike manufacturers. The Bosch Purion display is a bit limited but leaves plenty of room for Trek Blendr stem mounted accessories. Bosch CX motor is powerful, but louder than some competing products

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

High-performance hydroformed alloy, Removable Integrated Battery, Range Boost compatible, internal cable routing, Motor Armor, post-mount disc, 135x5mm QR

Fork

SR Suntour Mobie25, coil spring, tapered alloy steerer, preload, rebound, lockout, post mount disc, 100x15mm thru-axle, 50mm travel

Travel50mm

Spring TypeCoil

Headset

FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom

Stem

Size: M, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: L, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: XL, Bontrager alloy, 31.8mm clamp, Blendr compatible, 7 degree, 100mm length

Handlebar

Size: M, Bontrager alloy, 31.8mm, 15mm rise, 600mm width; Size: L, XL, Bontrager alloy, 31.8mm, 15mm rise, 660mm width

Saddle

Bontrager Commuter Comp

Seatpost

Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 400mm length

TypeRigid

Pedals

Bontrager Satellite City pedal

Grips

Bontrager Satellite Elite, alloy lock-on

Groupset
Rear Derailleur

Shimano Alivio T4000, long cage

Crank

Size: M, ProWheel alloy, 170mm; Size: L, XL, ProWheel alloy, 175mm

Shifters

Shimano Alivio M4000, 9 speed

Cassette

Shimano HG200, 11-36, 9 speed

Chain

KMC X9

Brakes

Shimano MT520 4-piston hydraulic disc, post-mount 180mm rotor

TypeHydraulic Disc

Wheels
Rims

Alex MD35, Tubeless Ready, 32-hole, 35mm width, presta valve

Spokes

J-Bend, 14g, Steel, Black

Front Hub

Bontrager Disc, 32-hole, 6-bolt disc, 15mm alloy thru-axle

Rear Hub

Bontrager sealed cartridge bearing rear hub, 32-hole, 6-bolt disc, 5mm QR

Tires

Schwalbe G-One, 650Bx57c

Disc Rotors

Shimano RT26, 180mm, 6-bolt

Electric Components
Motor

Bosch Performance Speed, 75 Nm, 28 mph / 45 kph

Battery

Bosch PowerTube 500

Recycling Program♻️ Call2Recycle

Charger

Bosch standard 4A (100-240V) charger

Accessories
Lights

Size: M, L, XL, AXA Blueline taillight; Size: M, L, XL, Herrmans MR8

Racks

Racktime Lightit
