2019 Transition

PATROL ALLOY COMPLETE GX

A 27.5″ aluminum frame full suspension enduro bike with high-end components.
Compare the full range

Manufacturer Price

$4,399
Weight33.2 lbs
FrameAluminum
SuspensionFull, 160 / 170mm
ForkFox Performance Elite Float 36
ShockFox Float DPX2 Performance Elite
Wheels27.5″ Aluminum
Drivetrain1 × 12
GroupsetGX Eagle, Truvativ Descendant
BrakesHydraulic Disc
SeatpostDropper
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
PATROL ALLOY COMPLETE GX
Other Enduro bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

26 mph

PATROL ALLOY COMPLETE GX

26 mph

Similar Bikes

Highest gear

(descending)

Sizing
XS

4'8" – 5'3"

SM

5'0" – 5'7"

MD

5'4" – 6'0"

LG

5'8" – 6'3"

XL

6'0" – 6'7"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Reviews
Mountain Bike Action
First Look Video: Transition Patrol Carbon - Mountain Bike Action Magazine

Nov 2019 · Brandon

Transition found a way to make the Patrol even rowdier. With the addition of a coil...

Read Review

Freehub
Bike Review | Transition Patrol NX

Sep 2019

Transition’s Patrol might be the most well-known bike in the Pacific Northwest. As the company’s home territory, there’s good reason for the Patrol’s ubiquity: It was designed for the exact type of steep and rugged trails that so many people in this region ride. The fine folks at Transition Bikes put in plenty of time partying in the woods to know exactly what attributes pair best with the rowdy creations of the PNW’s most renowned trailbuilders. And so, to create a bike that thrives in the steeps and excels when hucking to flat, they’ve done a few things differently. Debuting in 2015, when Transition implemented its Giddyup suspension platform, the Patrol immediately turned heads and catapulted the brand into the mainstream spotlight. Four years later, the model is still running strong and setting the bar for long-travel 27.5-inch bikes. A substantial change was made in 2018 with the addition of Speed Balanced Geometry, the company’s approach to evolving frame geometry and numbers to make the most out of the changes that mountain bikes have gone through in recent years. Essentially, what SBG does is increase the reach, shorten the stem, steepen the seat tube, slack out the head tube angle and reduce the fork offset. While this might seem like a lot of individual adjustments, they’re all made with one goal in mind: changing the steering trail to conform with modern frame designs. This, in turn, changes the steering and front end feelings of the bike, increasing front wheel traction and high-speed stability. Well, it sure is hard to argue with logic and math, and the folks at Transition have been carving out their own (extremely creative) path for a while, so if they’re willing to take this leap, I’m guessing there’s some truth to it. After putting the Patrol Carbon NX through its paces for the better part of nine months, and riding everything between Bellingham, WA and Whistler, BC—which is exactly what they had in mind while designing SBG—I can attest that these guys are on to something.

Read Review

Revolution Mountain Bike Magazine
On [R]eview: Transition Patrol Carbon

Mar 2019

Now you sure as hell don’t need me to sit here and tell you that Transition bikes have earned themselves a mighty reputation in recent years for delivering some of the nicest rigs on the market, needless to say, whenever we get the chance to spend some quality time testing one of their new whips we certainly look forward to the opportunity. What could be described as the party animal of the Transition line up would be the brand new […]

Read Review

BIKE Magazine
Dream Build: Anthony Smith's Transition Patrol Carbon

Oct 2018

Transition started a short-offset movement with its new SBG geometry, and for his dream build, Photo Editor Anthony Smith asked, "How far can I take this?"

Read Review

BikeRadar
Transition Patrol NX review

May 2018 · Rob Weaver

A truly capable frame that encourages flat-out fast riding but is ultimately held back by some elements of the spec, which is a shame at this price. Buy if you’re in the market for a downhill bomber and can live with the weight on the climbs

Highs
  • Great geometry that feels calm and capable at speed, smooth well-balanced rear suspension, solidly built and reasonably quiet

Lows
  • Brakes lack power, fork can struggle in the really rough stuff, not as lively on flatter trails

Read Review

NSMB
2017-transition-patrol-carbon

Apr 2017

2017 Transition Patrol Carbon Long Term Review

Read Review

Dirt Mountainbike
Transition Patrol Carbon 2

Mar 2017 · Smurf

A bike that's truly deserving of its accolades

Read Review

Bicycling
Tested: Transition Patrol Carbon 2

Dec 2016 · Louis Mazzante

Rip turns ferociously on this notably agile all-mountain bike

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Patrol Alloy 160mm Rear/170mm Front

Fork

Fox 36 Grip 2 Performance Elite 170mm

Travel170mm

Spring TypeAir

Shock

Fox DPX2 Performance Elite

Travel160mm

Spring TypeAir

Headset

FSA No.57E

Stem

RaceFace Aeffect R (40mm)

Handlebar

RaceFace Chester 35, XS (760 x 10mm), SM (780 x 20mm), MD/LG/XL (780 x 35mm)

Saddle

ANVL Forge Cromo

Seatpost

RockShox Reverb Stealth 1x Remote, XS (100mm), SM (125mm), MD (150mm), LG/XL (170mm)

TypeDropper

Grips

ODI Elite Flow

Groupset
Rear Derailleur

SRAM GX Eagle

Crank

SRAM Descendent 7K DUB (170mm x 32t)

Shifters

SRAM GX Eagle

Cassette

SRAM XG 1275 (10-50t)

Chain

SRAM GX Eagle

Brakes

SRAM Code RSC

TypeHydraulic Disc

Wheels
Rims

Stans Flow S1 Team

Tires

Front: Maxxis Minion DHF 3C WT (27.5x2.5), Rear: Maxxis Minion DHRII 3C WT (27.5x2.4)

Disc Rotors

SRAM Centerline (180mm)

Rider Notes
