2023 Tern
GSD S10 LX
A 20″ aluminum frame long tail cargo e-bike with upper mid-range components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
$4,999| Weight | 74.0 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Hardtail, 70mm |
| Fork | Suntour |
| Wheels | 20″ Aluminum |
| Drivetrain | 1 × 10 |
| Groupset | Deore |
| Motor | Bosch 85Nm mid-drive |
| Battery | Bosch 500Wh |
| Brakes | Hydraulic Disc |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full GSD model range
View Comparison
Dec 2022 · James Huang
A host of subtle, but highly functional, updates make an already-fantastic cargo bike option even better.
Ultra-compact size combined with full-sized hauling capability, super broad array of accessories, improved ride and handling, quieter and more powerful motor, great range, generally excellent spec.
Finicky kickstand, 20″ front wheel still makes for somewhat twitchy handling, one-size-doesn’t-really-fit-all.
Aug 2021 · Sam Gross
In this Tern GSD S00 LX review we discuss with Tern what makes this bike unique, while testing out handling, motor, and brake capabilities.
Dec 2020
If you want a versatile, easily-adjustable load carrier and you’ve got the pockets for it, the Tern GSD S10 is as good as they come, carrying people and packages with consummate ease. The updates from the first version have made it a better overall bike, at the expense of, well, some extra expense. This remains, though, the best option for nearly anyone doing normal things on a bike, assuming you can afford it. The other builds are even more expensive than the S10, which starts at £4,499, but for me this is the model to go for.
Aug 2020
The new GSD G2 is Tern's new version of its high-in-demand electric cargo bike. Improved features and a new safety standard help you GSD.
Aug 2020
The revamped bike includes a high-torque motor, suspension fork, brake lights, wheel lock, and other useful additions.
Powerful Bosch Cargo Line motor
Locking kickstand with remote release
Suspension fork
Brake lights and high/low beam headlights
Jul 2020 · Philipp Schwab
Is the Tern GSD S00 E-cargo bike literally living on the edge? Is putting a 115 kg rider on the smallest bike in the test a recipe for disaster? We sent our biggest test rider to check whether this little E-cargo bike is bombproof. Equipped with a dual battery system and two bottles of beer, the little Tern had to show what it's capable of!
Can be stowed anywhere thanks to its compact dimensions, even fitting in the back of an estate!
Well thought out concept, standard euro boxes fit the rack perfectly
Comfortable tire-rim combination
Convenient manoeuvring handle on the saddle
Low-slung frame
Limited climbing capabilities due to the limited gear range of the Enviolo Cargo drivetrain
Nervous handling, especially without a load
Old generation Bosch Performance Line CX motor
Wobbly stand that is difficult to fold out
| Frame | Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg Colors: Dragon Fruit; School Bus Yellow; Blue Grey |
|---|---|
| Fork | Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg Travel: 70mm |
| Bottom Bracket | Motor integrated |
| Headset | Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated |
| Stem | Tern Andros, adjustable, forged construction, patented technology |
| Handlebar | Tern Sweep, 6061-AL, Tern Andros adapted |
| Saddle | Tern GSD by Velo, with rear handle |
| Seatpost | Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm Type: Rigid |
| Pedals | Urban with non-slip surface, sealed bearings |
| Rear Derailleur | Shimano Deore Shadow+ |
|---|---|
| Crank | Tern GSD custom, forged 6061-AL DH crankarm |
| Shifters | Shimano Deore, 1 x 10 spd |
| Cassette | Shimano 11-42T, 10 spd |
| Chain | 10 spd, DHT for eBike, GST corrosion resistant coating |
| Chain Guide | Tern Custom, full chain cover |
| Brakes | Hydraulic Disc Type: Hydraulic Disc |
| Brake Levers | Magura MT5 e-stop, hydraulic, with brake sensor |
| Rims | Tern Atlas, ultra wide 36 mm, dual reinforced joint |
|---|---|
| Front Hub | Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing |
| Rear Hub | Tern Atlas, Boost Thru-Axle, Syntace X-12 standard, Cargo-optimized design |
| Tires | F: Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex |
| Motor | Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
|---|---|
| Battery | Bosch Dual Battery system, 500 Wh/1000 Wh Recycling Program: ♻️ Call2Recycle |
| Lights | Ignis Headlight, Ultra wide 700 lumens, Hi/Lo Beam |
|---|---|
| Fenders | Integrated Wheel Guard, AL6061, w/ Side Skirt |
| Racks | Combo Mount |
Last updated May 18
