73mm shell width, threaded standard English (1.37˝ x 24t)

Disc and rim brake compatible. Disc mounts are 51mm IS Rim brake pivots are removable. Note: rear disc brake is limited to 160mm maximum rotor diameter and requires the use of Surly caliper adapter (included with frames and bikes)

TIG-welded tapered & butted 4130 CroMoly, 100mm suspension corrected, tapered straight blade. Low- and mid-blade fully threaded through-blade rack eyelets; fender mount eyelets at dropout; 1-1/8˝ x 260mm threadless steer tube, 51mm disc mount (203mm max. rotor diameter), removable cantilever pivots, two sets of bottle mounts on each fork blade. Note: you can’t always mount bottles on the fork with every rack

Surly 4130 CroMoly steel. Main triangle is double-butted. TIG-welded.

When we designed our Troll frame we set out to design a bike frame that would be, to its rider, a blank canvas upon which they could paint a masterpiece of versatility. The kind of frame that could be built using any kind of parts for any kind of purpose, be it riding the local backyard singletrack, getting to work, the store, or around the whole darn world.
Those familiar with the standard Troll frame know that you can pretty much put anything on it you want. Disc brakes? Yep. Linear pull or cantilever brakes? Indeed. Racks, disc brakes and fenders all at once, both front and rear? Totally. The point is that the World Troller can do everything the standard Troll frame can, plus it’ll bust in half via two S&S Machine frame couplers so you can fit it in an airline approved travel case, potentially costing you less to get your bike to whatever far-flung location you have decided to explore (make sure to check with your airline). We do advise that to properly make use of the option this frame provides, a certain level of mechanical aptitude is required. You have been warned.
Compared to 700c wheels, the 26” wheels of the World Troller have some advantages. 26” wheels are stronger than their larger counterparts, can be easier to find parts and tires for in many places around the world and pack more easily because of their smaller size. The World Troller, buy a one-way ticket to anywhere and ride your ass back home.

Surly World Troller Frameset

A steel frame touring frameset with rim brakes.

Frame	Steel
Fork	Steel
Wheels	700c
Brakes	Rim

Frame	Surly 4130 CroMoly steel. Main triangle is double-butted. TIG-welded. BB Standard: BSA, 73mm, Threaded Tire Clearance: 2.75"
Fork	TIG-welded tapered & butted 4130 CroMoly, 100mm suspension corrected, tapered straight blade. Low- and mid-blade fully threaded through-blade rack eyelets; fender mount eyelets at dropout; 1-1/8˝ x 260mm threadless steer tube, 51mm disc mount (203mm max. rotor diameter), removable cantilever pivots, two sets of bottle mounts on each fork blade. Note: you can’t always mount bottles on the fork with every rack
Bottom Bracket	73mm shell width, threaded standard English (1.37˝ x 24t)
Seatpost	27.2mm Type: Rigid

2017 SurlyWorld Troller Frameset

2017 Surly
World Troller Frameset
