Shiny Petrol

Stealth Black

Front: Shimano BR-MT200, Hydraulic disc brake, Rear: Shimano BR-MT200, Hydraulic disc brake

Shimano CS-HG200, 9-speed, Combination: 11-13-15-17-20-23-26-30-36 T

Shimano FC-MT210-2, 36-22 T, BB type: BSA 73 mm / 2-Piece

SR Suntour XCR32 LO-R, Travel: 100 mm, Coil spring, Lockout, Steerer 1 1/8", O.L.D.: 100 mm, Brake: postmount disc 6"

Aluminium 6061 DB, O.L.D.: 135 mm, Brake: IS disc, BB: BSA 73 mm, Front derailleur mount: clamp, Cable routing: internal (shifting)/external (brake), Rack mounts

Oxygen Driver, Width: 700 mm, Backsweep: 9°, Rise: 25 mm, Clamp: 31.8 mm

STEVENS AH 1 1/8", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30

Shimano Alivio Shadow, RD-M3100-SGS, 9-speed, Total capacity: 45 T

Oxygen Driver, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm

Oxygen Driver, Handlebar clamp: 31.8 mm, Angle: 6°

Schwalbe Smart Sam Active-Line, Tire size: 27.5": 57-584 | 29": 57-622, SBC compound, KevlarGuard

Faithful trail companion. This comfortable STEVENS hardtail is an attractive offer for you first off-road miles. Depending on frame size with either 27.5 or 29" wheels. Thanks to reliable and robust Shimano and Oxygen components rides will be fun for a long time - even in frame size 24in.

Stevens Taniwha

A 27.5″ aluminum frame hardtail crosscountry bike with mid-range components.

Weight	30.6 lbs
Frame	Aluminum
Suspension	Hardtail, 100mm
Fork	Suntour XCR
Wheels	27.5″ Aluminum
Drivetrain	2 × 9
Groupset	Alivio
Brakes	Shimano Hydraulic Disc

Frame	Aluminium 6061 DB, O.L.D.: 135 mm, Brake: IS disc, BB: BSA 73 mm, Front derailleur mount: clamp, Cable routing: internal (shifting)/external (brake), Rack mounts BB Standard: BSA, 73mm, Threaded Colors: Shiny Petrol; Stealth Black
Fork	SR Suntour XCR32 LO-R, Travel: 100 mm, Coil spring, Lockout, Steerer 1 1/8", O.L.D.: 100 mm, Brake: postmount disc 6" Travel: 100mm Spring Type: Coil
Bottom Bracket	BSA, 73mm, threaded
Headset	STEVENS AH 1 1/8", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30
Stem	Oxygen Driver, Handlebar clamp: 31.8 mm, Angle: 6°
Handlebar	Oxygen Driver, Width: 700 mm, Backsweep: 9°, Rise: 25 mm, Clamp: 31.8 mm
Saddle	Oxygen Raceline
Seatpost	Oxygen Driver, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm Type: Rigid
Pedals	MTB Flatpedal Reflex

Rear Derailleur	Shimano Alivio Shadow, RD-M3100-SGS, 9-speed, Total capacity: 45 T
Front Derailleur	Shimano Alivio, FD-M3120-M, 2-speed
Crank	Shimano FC-MT210-2, 36-22 T, BB type: BSA 73 mm / 2-Piece
Shifters	Shimano Alivio, SL-M3100, 2-speed
Cassette	Shimano CS-HG200, 9-speed, Combination: 11-13-15-17-20-23-26-30-36 T
Chain	Shimano CN-HG53
Brakes	Front: Shimano BR-MT200, Hydraulic disc brake, Rear: Shimano BR-MT200, Hydraulic disc brake Type: Shimano Hydraulic Disc
Brake Levers	Shimano BL-MT200, 3 finger

Rims	Oxygen RM-M19, ETRTO: 19 x 584
Front Hub	Shimano HB-TX505, Axle: QR9x100 mm
Rear Hub	Shimano FH-TX505-8, Axle: QR10x135 mm
Tires	Schwalbe Smart Sam Active-Line, Tire size: 27.5": 57-584 \| 29": 57-622, SBC compound, KevlarGuard

2022 StevensTaniwha

2022 Stevens
Taniwha
