Today’s Deals2023 Silverback
S-Electro Diamond Step 1
A 29″ aluminum frame hardtail trail e-bike with upper mid-range components.
Compare the full range
Manufacturer Price
€3,999($4,653)| Weight | 47.4 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Hardtail, 120mm |
| Fork | Suntour RAIDON |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 11 |
| Groupset | Deore |
| Motor | Shimano 85Nm mid-drive |
| Battery | 720Wh |
| Brakes | Shimano Hydraulic Disc |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full S-Electro model range
View Comparison5'0" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'0" – 6'11"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | Aluminium E - MTB frame designed to take a 720wh battery and Shimano STEPs EP8, E8000 or E7000 motor. The geometry is designed for an all day easy trail ride or a commute to your preferred destination. This is a Step through frame making it easier to get your leg over the TT. This frame has tyre clearance for 29 x 2,6" tyres. Sizes range from S - XL BB Standard: STEPS, Press Fit Tire Clearance: 2.6" Color: Rainbow Pearl |
|---|---|
| Fork | Suntour SF19 Raidon32-DS-Boost-RL-R-15QLC32 29 CTS, 120mm Travel, Tapered Steerer, Matt Black, Boost 110mm Thru Axle Travel: 120mm Spring Type: Air |
| Bottom Bracket | STEPS, press-fit |
| Headset | Token TK035A-15 Sealed Bearing |
| Stem | SURFACE High-Rise alloy |
| Handlebar | SURFACE Alloy, Dia:31.8mm, Backsweep:9°, Rise 5mm |
| Saddle | SURFACE E-BIKE saddle, Cromo Rails |
| Seatpost | SURFACE Suspension Post w/Protective Cover, 30.9mm Type: Suspension |
| Grips | SURFACE ERGO |
| Rear Derailleur | Shimano RD-M5100 Deore, 11 Speed |
|---|---|
| Crank | Shimano FC-EM600 |
| Shifters | R: Shimano SL-M5100-R Deore, 11 Speed Rapidfire Plus |
| Cassette | Shimano CS-M5100 Deore, 11 Speed 11-51T |
| Chain | Shimano CN-HG601-11, 11spd |
| Brakes | F: Shimano MT200, Resin Pads Type: Shimano Hydraulic Disc |
| Rims | F: SUNringlé Duroc 35, STR Tubeless, 32mm Internal Width |
|---|---|
| Front Hub | F: Shimano HB-MT410-B, 32H, 15mm Thru-Axle, 110mm OLD |
| Rear Hub | F: Shimano HB-MT410-B, 32H, 15mm Thru-Axle, 110mm OLD |
| Tires | F: Maxxis Forekaster 29 x 2,35", 120 tpi, EXO |
| Disc Rotors | F: Shimano SM-RT10 180mm |
| Motor | Shimano EP8 Drive Unit, Mid-Position, 25km/h, 85N.m Torque |
|---|---|
| Battery | Darfon 720Wh, 36V, 20Ah Li-Ion, 3.8Kg Weight |
| Display | Shimano SC-E7000, 31.8mm |
| Charger | Darfon Smart Plus, 100-240V, 4A, EU use |
