2022 Schwinn
Fastback Carbon 105
A carbon frame endurance bike with upper mid-range components and rim brakes.
Compare the full range
Manufacturer Price
$2,299| Frame | Carbon |
|---|---|
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 11 |
| Groupset | 105 |
| Brakes | Rim |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Fastback model range
View Comparison5'1" – 5'6"
5'4" – 5'9"
5'7" – 6'0"
5'10" – 6'3"
6'0" – 6'5"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | N LITENED Black Label carbon, 700c road tuned geometry, internal cable routing, 10 mm x 135 mm dropout, replaceable hanger, tapered headtube |
|---|---|
| Fork | Schwinn carbon race, 700c, carbon tapered steerer, 9 mm x 100 mm QR |
| Bottom Bracket | Shimano, sealed external bearing, 68 mm |
| Headset | Threadless, IS42 / IS52, sealed bearings |
| Stem | Schwinn, aluminum, threadless, - 7° rise, 31.8 mm clamp |
| Saddle | Schwinn S1 race, steel rails |
| Seatpost | Aluminum, 300 mm, 16 mm offset, 31.6 mm Type: Rigid |
| Pedals | Schwinn road, nylon, toe clips and straps |
| Grips | Schwinn road, Silicon gel tape |
| Rear Derailleur | Shimano 105 RD-R7000 |
|---|---|
| Front Derailleur | Shimano 105 FD-R7000, 34.9 mm clamp |
| Crank | Shimano 105 FC-R7000, 50/34T |
| Shifters | Shimano 105 ST-R7000, 22-speed |
| Chain | Shimano CN-HG601 |
| Brakes | Shimano 105 BR-7000, dual pivot caliper, aluminum Type: Rim |
| Rims | Shimano WH-RS100, aluminum, double wall, 20H front, 24H rear |
|---|---|
| Spokes | 14G, stainless steel |
| Rear Hub | Shimano WH-RS100, aluminum, 10 mm x 130 mm QR, 24H |
| Tires | Kenda Kriterium, 700c x 25c, folding bead |
