2019 Raleigh
Lore iE Step Over
A 650b aluminum frame hybrid e-bike with upper mid-range components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
$3,499| Frame | Aluminum |
|---|---|
| Suspension | Hardtail, 120mm |
| Fork | RockShox Judy |
| Wheels | 650b Aluminum |
| Drivetrain | 1 × 10 |
| Groupset | Deore, FSA |
| Motor | Bosch 350W 63Nm mid-drive |
| Battery | Bosch 500Wh |
| Brakes | Hydraulic Disc |
For This Bike
Jan 2019
Price: $4599.00 | Model Year: 2019 A stealthy full suspension 28mph urban electric bike with comfortable plus sized tires, sturdy thru-axles with wider Boost hub spacing, lightweight 130mm air suspension from RockShox. Available in three frame sizes and designed with a lower top tube for approachability, you could swap the slick tires out for knobby and use this as a cross country electric mountain bike. A stealthy full suspension 28mph urban electric bike with comfortable plus sized tires, sturdy thru-axles with wider Boost hub spacing, lightweight 130mm air suspension from RockShox.
A stealthy full suspension 28mph urban electric bike with comfortable plus sized tires, sturdy thru-axles with wider Boost hub spacing, lightweight 130mm air suspension from RockShox
Available in three frame sizes and designed with a lower top tube for approachability, you could swap the slick tires out for knobby and use this as a cross country electric mountain bike
High performance Bosch Speed motor with shift detection, larger PowerPack 500 battery provides excellent range while remaining lightweight, great 10-speed Shimano Deore drivetrain with one-way clutch to reduce chain bounce, upgraded Bosch Kiox display panel
Powerful and consistent Magura hydraulic disc brakes with larger 203mm front rotor and quad-piston calipers for consistency and cooling at high speed, great locking ergonomic grips, solid Wellgo platform pedals, wider 31.6mm seat post for easy dropper post upgrade, matching black accents all around (including rims, spokes, and hubs)
| Frame | Hydroformed Aluminum Alloy 6061 T6, Trail Speed Geometry |
|---|---|
| Fork | Rock Shox Judy Gold 120mm 27.5+ Travel: 120mm Spring Type: Coil |
| Headset | Integrated, Sealed Bearing |
| Stem | Raleigh Aluminum Alloy, 3D Forged, +/-7 Degree |
| Handlebar | Raleigh Flat Bar, 6061 Aluminum Alloy |
| Saddle | Raleigh Custom Ergo Performance |
| Seatpost | Raleigh Aluminum Alloy, Forged Head Type: Rigid |
| Pedals | Alloy Cage w/Sealed Bearings and Crmo Axles |
| Grips | Raleigh Ergo Comfort Control |
| Rear Derailleur | Shimano Deore M6000, GS, Shadow Plus |
|---|---|
| Crank | FSA Forged Alloy, 170mm Annodized Black |
| Shifters | Shimano Deore M6000, 10 Speed |
| Cassette | FSA Forged Spider, 20 Tooth w/Chainguard, Steel |
| Chain | KMC x10ePT Ebike Specific |
| Brakes | Magura Fifty4, 4 Piston Front 203mm Rotor, 2 Piston Rear 180mm Rotor Type: Hydraulic Disc |
| Brake Levers | Magura, HC Carbon Levers |
| Rims | 27.5", Thru axle, 45mm ID, Disc Specific, Tubeless Ready |
|---|---|
| Spokes | Black w/Silver Brass Nipples |
| Front Hub | Formula, Sealed Bearing, Thru Axle, Boost 110, 32 Hole |
| Rear Hub | Formula, Sealed Bearing, Thru Axle, Boost 148, 32 Hole |
| Tires | 27.5 x 2.8" Schwalbe Super Moto -X, RaceGuard |
| Motor | Bosch Performance Speed, 350W (575 max), 63Nm Torque, 28mph |
|---|---|
| Battery | Bosch Powerpack 500Wh, DT Mount |
| Display | Bosch Purion Performance Line |
