2019 Propain
Rage CF 29 Highend
A 29″ carbon frame full suspension downhill bike with ultra high-end components.
Compare the full range
| Weight | 34.4 lbs |
|---|---|
| Frame | Carbon |
| Suspension | Full, 200 / 190mm |
| Fork | Fox Factory Float 49 |
| Shock | Fox Float DHX2 Factory |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 7 |
| Groupset | X01 |
| Brakes | Hydraulic Disc |
For This Bike
Oct 2020 · Propain Factory Racing
The bike is set up with a mixed wheel size configuration and has 215mm of travel, the same as the current rage.
| Frame | Carbon Fiber |
|---|---|
| Fork | FOX 49 Factory Air, Kashima, low and high speed rebound and compression Travel: 190mm Spring Type: Air |
| Shock | FOX DHX2 Factory Coil, Kashima, 250mm x 70mm, 8x25mm upper and lower mounts Travel: 200mm Spring Type: Air |
| Bottom Bracket | SRAM GXP 83mm |
| Headset | IS42 top bearing, IS42 bottom bearing |
| Stem | Sixpack Skywalker, direct mount |
| Handlebar | Sixpack Millenium carbon, 785mm width |
| Saddle | Selle Italia XR |
| Seatpost | Sixpack Menace Type: Rigid |
| Pedals | None included (upgrade options available) |
| Grips | Single clamp, nine color options available |
| Rear Derailleur | SRAM X01 DH, 7-speed |
|---|---|
| Front Derailleur | N/A |
| Crank | SRAM X01 Carbon DH 165mm |
| Shifters | SRAM X01 DH, 7-speed |
| Cassette | SRAM X01 DH XG-795, 10-24 tooth, 7-speed |
| Chain | SRAM PC-1110 |
| Chain Guide | MRP G3 mini |
| Brakes | Magura MT7, 4-piston with 203mm rotors (front and rear) Type: Hydraulic Disc |
| Brake Levers | Magura MT7 |
| Rims | Stan's ZTR Flow MK3, 29mm inner width |
|---|---|
| Spokes | DT Swiss Competition |
| Front Hub | Propain, Enduro bearings |
| Rear Hub | Propain, Enduro bearings |
| Tires | Schwalbe Magic Mary EVO, DH, Addix U-soft, wire bead, 29 x 2.35" |
