Today’s Deals2023 Panorama
Katahdin
A carbon frame gravel bike with upper mid-range components and shimano grx 600 hydraulic disc brakes.
Compare the full range
Manufacturer Price
CA$3,739($2,709)| Weight | 3.0 lbs (frame) |
|---|---|
| Frame | Carbon |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | GRX 800, GRX 600 |
| Brakes | Shimano GRX 600 Hydraulic Disc |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Katahdin model range
View Comparison5'4" – 5'8"
5'6" – 5'11"
5'9" – 6'3"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, INTERNAL CABLE ROUTING FOR ADJUSTABLE SEATPOST, BRAKE STD: FLAT MOUNT, REAR RACK MOUNTS, WATER BOTTLE MOUNTS UNDER AND OVER THE DOWNTUBE, WATER BOTTLE MOUNTS ON SEAT TUBE, GAS TANK MOUNT ON TOP OF TOP TUBE, FENDER MOUNTS, 12MMX142MM REAR SPACING, BSA 68mm BOTTOM BRACKET, TAPERED 1-1/2¨ x 1-1/8¨ HEAD TUBE, INTEGRATED HEADSET: TOP IS42 LOWER IS52, DIA 31.8MM SEAT POST CLAMP, DIA 27.2MM SEAST POST, FRONT DERAILLEUR: BRAZE-ON REPLACEABLE, MAXIMUM TIRE CLEARANCE: 700X48MM OR 650X2.1¨, COMPATIBLE DI2, MAX CHAINRINGS: 2X 50/34T, 1X 46T, FRAME WEIGHT: 1350g (LARGE), COLOR: OLIVE GREEN KHAKI BB Standard: BSA, 68mm, Threaded Tire Clearance: 47c Color: Olive Green Khaki |
|---|---|
| Fork | HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, TRIPLE CARGO CAGE MOUNTS, FENDER MOUNTS, 12MMX100MM SPACING, INTERNAL CABLE ROUTING FOR DYNAMO HUB, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE : 700X50MM OR 650X2.1¨, COLOR: OLIVE GREEN KHAKI |
| Bottom Bracket | SHIMANO BBR60 ULTEGRA |
| Headset | FSA NO.42 IS |
| Stem | PROMAX DA-281, 31.8MM, 6DEG |
| Handlebar | RITCHEY COMP BUTANO V2, 46CM |
| Saddle | WTB SILVERADO MEDIUM |
| Seatpost | KALLOY SP-3D2 Type: Rigid |
| Pedals | Not included |
| Rear Derailleur | SHIMANO RX822, GRX, SGS 12-SPEED |
|---|---|
| Front Derailleur | N/A |
| Crank | SHIMANO GRX RX610 38T 1X12, 170/172.5/175mm |
| Shifters | SHIMANO GRX RX610 (left lever is 2x compatible) |
| Cassette | SHIMANO M7100-12, DEORE SLX, 10-51T, 12-SPEED |
| Chain | SHIMANO M7100, DEORE SLX, 12 SPEED |
| Brakes | SHIMANO GRX RX610 (left lever is 2x compatible) Type: Shimano GRX 600 Hydraulic Disc |
| Rims | HUNT 4SEASON GRAVEL DISC X WIDE 700c |
|---|---|
| Tires | MAXXIS RAMBLER, 700X45, EXO/TR, 60TPI, TANWALL |
| Disc Rotors | SHIMANO RT64 160MM CENTERLOCK OR SRAM CENTERLINE 160MM CENTERLOCK |
