Today’s Deals2026 Orbea
CARPE 10
A 700c aluminum frame commuter e-bike with high-end components and shimano hydraulic disc brakes.
Compare the full range
Manufacturer Price
£3,799($5,111)| Frame | Aluminum |
|---|---|
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | Belt Drive, Internally Geared Hub |
| Groupset | Gates CDX |
| Motor | Shimano 600W 85Nm mid-drive |
| Battery | 420Wh |
| Brakes | Shimano Hydraulic Disc |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full CARPE model range
View Comparison5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Mar 2026 · Travis Reill
Orbea's Carpe e-bike is unapologetically an urban and commuting machine with folding stem, folding pedals, and all the accessories
| Frame | Orbea Carpe 2026, Hydroformed Alloy 6061, OLD 135x9 / OLD 142x12, Headset Standard HS01, Orbea cockpit and equipment ecosystem, w/ Kickstand, Trailer compatible. BB Standard: BSA, Threaded Colors: Nickel (Matt); Mars Red (Gloss); Diamond Black (Matt) |
|---|---|
| Fork | Orbea Carpe carbon |
| Bottom Bracket | BSA, threaded |
| Stem | ST 0.1 Foldable 65mm, +15º |
| Handlebar | Alloy, 31.8mm, Riser |
| Saddle | Selle Royal Vivo Ergo |
| Seatpost | SP08, Alu, 31.6mm, Setback 0, w/integrated lightu Type: Rigid |
| Pedals | VP-F57 Foldable pedal black with reflectors |
| Crank | Gates CDX 50t w/chainguard |
|---|---|
| Shifters | EN600-R |
| Cassette | Gates CDX 34t for Shimano Inter 5e |
| Chain | Gates CDX Belt |
| Chain Guide | Gates CDS |
| Brakes | Shimano MT200 Hydraulic Disc Type: Shimano Hydraulic Disc |
| Rims | Alloy, 25c, 32H |
|---|---|
| Tires | Vittoria Randonneur 42-622, Reflective band |
| Motor | Shimano EP600 |
|---|---|
| Battery | Orbea Internal 420Wh |
| Display | Shimano EN500 |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
| Lights | Front: Supernova Mini2, Rear: Supernova TL3 Mini |
|---|---|
| Fenders | Orbea Alu SL 48 |
| Racks | Front: N/A, Rear: Orbea RR-01 Alloy, w/Mik & Mik Side and Ortlieb QL3.1 system. Max. 20Kg |
| Lock | Abus 5755L |
| Bell | Knog Oi Small Flat |
