2023 Orbea

VIBE H10 20mph

A 700c aluminum frame commuter e-bike with upper mid-range components and magura mt5 hydraulic disc brakes.

Manufacturer Price

$3,799
FrameAluminum
SuspensionRigid
ForkCarbon
Wheels700c Aluminum
Drivetrain1 × 12
GroupsetXT, Deore
MotorMAHLE hub-drive
BatteryMAHLE 248Wh
BrakesMagura MT5 Hydraulic Disc
View on orbea.comLearn about Orbea
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

33 mph

VIBE H10 20mph

31 mph

Similar Bikes

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Sizing
SM

4'11" – 5'6"

MD

5'4" – 6'0"

LG

5'10" – 6'6"

XL

6'4" – 6'9"

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Geometry
Specs
Build
Frame

Orbea Vibe Top Bar Hydro 6061 Hydroform Aluminum 2021, ICR cable routing, Forged BB, 135x9 QR, Flat Mount disc, 700x45 maximun tire, 1" 1/2 semi head set, 41x86,5 Pressfit BB, carrier and fenders compatible

BB Standard: BB86/BB92, 86mm, Press Fit

Colors: Metallic Night Black (Gloss); Blue (Gloss); Metallic Dark Red (Gloss); Urban Green (Gloss); Light Green (Gloss)

Fork

Orbea Vibe carbon fork, full carbon, 1-1/5, 700x45 maximun tire, flat mount disc mount, Thrue Axle12x100mm, Long mudguards compatible.

Bottom Bracket

BB86/BB92, 86mm, press-fit

Headset

Acros Alloy 1-1/2" Internal Cable Routing

Stem

Alloy forged, -6º, ICR

Handlebar

Alloy,31.8mm, Rise 12mm, 700mm

Saddle

Brooks Cambium C15 283x140

Seatpost

Alloy, 27.2mm, Setback 0, for integrated light

Type: Rigid

Pedals

VP-537 Black

Grips

Brooks Comfort Cambium 130mm

Groupset
Rear Derailleur

Shimano XT M8100 SGS Shadow Plus

Crank

Forged alloy, 42t, w/Chainguard

Shifters

Shimano Deore M6100

Cassette

Sun Race CSMZ80 11-51t 12-Speed Metalic E-bike

Chain

KMC X12

Brakes

Magura MT5 E-STOP Hydraulic Disc Easy Route Connection

Type: Magura MT5 Hydraulic Disc

Wheels
Rims

Alloy, Tubeless, 700c, 21c, 32H

Tires

Kenda K1052 700x45C Reflective type TLR

Electric Components
Motor

Mahle motor hub X35 Plus

Battery

Mahle 36V/6.9A 248Wh ANT+

Remote

Mahle iWoc TRIO

Charger

Mahle X35

Accessories
Lights

Lezyne FENDER STVZO seatpost mounting 11 lumens

Bell

Knog OI Classic
