2023 Orbea

URRUN 40

A 29″ aluminum frame hardtail crosscountry e-bike with upper mid-range components.
Compare the full range

Manufacturer Price

£3,099($3,924)
Price History
FrameAluminum
SuspensionHardtail, 100mm
ForkSuntour X1
Wheels29″ Aluminum
Drivetrain1 × 10
GroupsetDeore
MotorShimano 600W 85Nm mid-drive
Battery540Wh
BrakesHydraulic Disc
View on orbea.comLearn about Orbea
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
URRUN 40
Other Crosscountry bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

25 mph

URRUN 40

27 mph

Similar Bikes

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full URRUN model range

View Comparison
Sizing
SM

5'1" – 5'7"

MD

5'4" – 5'11"

LG

5'8" – 6'3"

XL

6'0" – 6'7"

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Price History
Reviews
BikeRadar
Orbea Urrun 10 review

Sep 2022 · Mick Kirkman

Spanish brand’s top-tier electric hardtail with lightweight motor and battery

Highs

  • Smooth welded monocoque chassis looks the business

  • Proprietary shimano ep8 rs system delivers smooth power and massive range

Lows

  • Steering and handling feels twitchy and unstable

  • Frame is rock solid and beats you up a bit on rough trails

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Orbea Urrun, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible

BB Standard: STEPS, Press Fit

Colors: Borealis Blue (Matt) - Luminous Yellow (Gloss); Glitter Anthracite (Gloss) - Black (Matt); Leo Orange (Gloss) - Black (Matt)

Fork

SR Suntour X1 Coil LO 100mm QR

Travel: 100mm

Spring Type: Coil

Bottom Bracket

STEPS, press-fit

Headset

FSA 1-1/2" Integrated Aluminium Cup

Stem

Alloy forged, 35mm interface, -6º, ICR

Handlebar

OC Mountain Control MC31, Rise20, Width 800

Saddle

Selle Royal Vivo 145x269mm

Seatpost

Alloy, 31.6mm, Setback 0

Type: Rigid

Pedals

VP-537 Black

Groupset
Rear Derailleur

Shimano Deore M5120 SGS Shadow Plus

Crank

Alloy EP8 32t

Shifters

Shimano Deore M4100

Cassette

Shimano CS-M4100 11-46t 10-Speed

Chain

KMC e10 Turbo Silver

Chain Guide

Orbea Rise chainguide

Brakes

Shimano MT200 Hydraulic Disc

Type: Hydraulic Disc

Wheels
Rims

Alloy, Tubeless, 29", 29c, 32H

Tires

Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR

Electric Components
Motor

Shimano EP600-RS

Battery

Orbea Internal 540Wh (Optional 250 Wh Range Extender)

Display

Shimano EN500

Charger

Orbea 2.Generation eBike Smart charger 42V/2-4A
