2023 Orbea
URRUN 40
A 29″ aluminum frame hardtail crosscountry e-bike with upper mid-range components.
Compare the full range
Manufacturer Price
£3,099($3,924)| Frame | Aluminum |
|---|---|
| Suspension | Hardtail, 100mm |
| Fork | Suntour X1 |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 10 |
| Groupset | Deore |
| Motor | Shimano 600W 85Nm mid-drive |
| Battery | 540Wh |
| Brakes | Hydraulic Disc |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full URRUN model range
View Comparison5'1" – 5'7"
5'4" – 5'11"
5'8" – 6'3"
6'0" – 6'7"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Sep 2022 · Mick Kirkman
Ride quality doesn’t quite live up to the Urrun’s million-dollar looks, due to the overly forward riding position
Smooth-welded monocoque chassis looks the business
Proprietary Shimano EP8 RS system delivers smooth power and massive range
Steering and handling feels twitchy and unstable
Frame is rock-solid and beats you up a bit on rough trails
| Frame | Orbea Urrun, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible BB Standard: STEPS, Press Fit Colors: Borealis Blue (Matt) - Luminous Yellow (Gloss); Glitter Anthracite (Gloss) - Black (Matt); Leo Orange (Gloss) - Black (Matt) |
|---|---|
| Fork | SR Suntour X1 Coil LO 100mm QR Travel: 100mm Spring Type: Coil |
| Bottom Bracket | STEPS, press-fit |
| Headset | FSA 1-1/2" Integrated Aluminium Cup |
| Stem | Alloy forged, 35mm interface, -6º, ICR |
| Handlebar | OC Mountain Control MC31, Rise20, Width 800 |
| Saddle | Selle Royal Vivo 145x269mm |
| Seatpost | Alloy, 31.6mm, Setback 0 Type: Rigid |
| Pedals | VP-537 Black |
| Rear Derailleur | Shimano Deore M5120 SGS Shadow Plus |
|---|---|
| Crank | Alloy EP8 32t |
| Shifters | Shimano Deore M4100 |
| Cassette | Shimano CS-M4100 11-46t 10-Speed |
| Chain | KMC e10 Turbo Silver |
| Chain Guide | Orbea Rise chainguide |
| Brakes | Shimano MT200 Hydraulic Disc Type: Hydraulic Disc |
| Rims | Alloy, Tubeless, 29", 29c, 32H |
|---|---|
| Tires | Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR |
| Motor | Shimano EP600-RS |
|---|---|
| Battery | Orbea Internal 540Wh (Optional 250 Wh Range Extender) |
| Display | Shimano EN500 |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
