2023 Orbea
MX 20 TEAM

A 20″ aluminum frame mountain youth bike with modest components and rim brakes.
Compare the full range

Manufacturer Price

£499($669)

Where to Buy

Similar Bikes

Top Comparison

Insights

Ride Feel

Based on frame geometry and build specs.

Handling

nimblestable

MX 20 TEAM

Other Mountain Youth bikes

Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

17 mph

MX 20 TEAM

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full MX model range

Geometry

Specs

Build

Frame	Orbea MX 20 6061 Aluminum 2021, 135x9 QR, V-Brake + IS Disc Mount, 27,2 Seat Post, Internal Cable Routing, Central kickstand compatible, removable hanger, Fender and Carrier ready. Colors: Indigo Blue (Matt) - Bright Red (Gloss); Lime Green-Watermelon Red (Gloss); Purple (Matt) - Mint (Gloss)
Fork	Orbea MX 20 6061 Aluminum 2021, 100x9 QR, V-Brake, Mini + Long Fender ready
Headset	VP-Z104PD 1-1/8" Semi-Cartridge
Handlebar	Orbea Alu integrated cockpit 540mm
Saddle	DDK D2005 237x141mm
Seatpost	Digit Alloy, 27.2mm, 250mm, Setback 0 Type: Rigid
Pedals	VP-229 Black with reflectors

Groupset

Rear Derailleur	Shimano Altus M310
Crank	Extra light 32t, 127mm, w/Chainguard
Shifters	Shimano SL-M315
Cassette	Sun Race CSM66 11-34t 8-Speed
Chain	KMC X8
Chain Guide	Orbea Junior Chainguide
Brakes	Junior alloy V-brake Type: Rim
Brake Levers	Junior V-Brake lever, alloy body and alloy lever, with reach adjustment

Wheels

Rims	Alloy, 20", 36H
Tires	Kenda Booster K1277 20x2.20" 30TPI

Accessories

Fenders	Orbea Custom fork
