Today’s Deals2023 Orbea
KATU-E 30
A 20″ utility e-bike with modest components and shimano hydraulic disc brakes.
Manufacturer Price
£2,399($3,218)| Suspension | Rigid |
|---|---|
| Wheels | 20″ Aluminum |
| Drivetrain | Internally Geared Hub |
| Groupset | Nexus |
| Motor | Bosch 600W 40Nm mid-drive |
| Battery | Bosch 400Wh |
| Brakes | Shimano Hydraulic Disc |
3'11" +
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | Orbea Katu 20" BB Standard: Bosch, Press Fit Colors: Urban Green (Gloss); Night Black (Gloss) |
|---|---|
| Fork | Orbea Katu |
| Bottom Bracket | Bosch, press-fit |
| Headset | 1-1/8" Semi-Integrated |
| Stem | Orbea Alu |
| Handlebar | Orbea City Riser Alu 660mm |
| Saddle | Selle Royal Milo Plus DR |
| Seatpost | Alloy, 31.6mm, Setback 0 Type: Rigid |
| Pedals | VP-537 Black |
| Crank | FSA Bosch-IG3 E-bike 44t |
|---|---|
| Shifters | Shimano SL-C6000 Nexus 8-Speed |
| Cassette | Shimano Nexus 18t |
| Chain | KMC Z510HX |
| Chain Guide | FSA Bosch IG3 44-46t |
| Brakes | Shimano MT200 Hydraulic Disc Type: Shimano Hydraulic Disc |
| Rims | Alloy, 20", 36H |
|---|---|
| Tires | Kenda 841 20x2.25 Reflex |
| Motor | BOSCH Active |
|---|---|
| Battery | BOSCH Performance 400Wh |
| Display | BOSCH Performance Purion |
| Charger | Compact Charger 2A (100-240V) Worldwide |
| Lights | Front: Spanninga Kendo XDAS Dinamo, Rear: Spanninga Pixeo |
|---|---|
| Fenders | SKS 20" 60mm |
| Racks | Aluminium Front Basket |
| Lock | Abus battery down tube lock |
First added November 26
Last updated December 16
Not listed for 868 days
