Today’s Deals2022 Orbea
KEMEN SUV 10
A 29″ aluminum frame commuter e-bike with high-end components and magura mt5 hydraulic disc brakes.
Manufacturer Price
£4,299($5,784)| Frame | Aluminum |
|---|---|
| Suspension | Hardtail, 100mm |
| Fork | Fox AWL |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 11 |
| Groupset | XT |
| Motor | Shimano 85Nm mid-drive |
| Battery | 540Wh |
| Brakes | Magura MT5 Hydraulic Disc |
| Seatpost | Dropper |
5'1" – 5'7"
5'4" – 5'11"
5'8" – 6'3"
6'0" – 6'7"
Apr 2023 · Warren Rossiter
Off-road capable commuter ebike
Great package
Huge range
Powerful motor
Brakes lack feel
Boost mode is overkill in standard setting
Jan 2023
Price: $4599.00 | Model Year: 2023 | An adventure touring ebike equipped with sturdy aluminum alloy fenders, bright well-positioned integrated lights, and an optional range extending battery pack shaped like a water bottle.
An adventure touring ebike equipped with sturdy aluminum alloy fenders, bright well-positioned integrated lights, and an optional range extending battery pack shaped like a water bottle.
Available in two frame styles and four frame sizes for improved fit, three colors to match your style or stand out for safety, and the purpose built frame protects and hides most cables and wires.
Knobby off-road tires include puncture protection and reflective stripes. Highly adjustable air suspension fork with sturdy Boost hub spacing, and 15mm thru-axle. Powerful Shimano EP8 mid-drive motor.
The primary battery pack is not easily removable for transport or charging. If you get the range extender, it must be charged independently from the main pack. The charge port is low on the frame near the left crank. The bike power button is separate from the control pad.
| Frame | Orbea Kemen Top Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible BB Standard: STEPS, Press Fit Colors: Urban Green (Gloss) - Black (Matt); Mango (Gloss) - Black (Matt); Metallic Night Black (Matt-Gloss) |
|---|---|
| Fork | Fox 34 Float AWL 100 RAIL QR15x110 Travel: 100mm Spring Type: Air |
| Bottom Bracket | STEPS, press-fit |
| Headset | FSA 1-1/2" Integrated Aluminium Cup |
| Stem | OC1 35mm interface -6º |
| Handlebar | OC 35mm 20mm Rise 780mm |
| Saddle | Selle Royal Vivo 145x269mm |
| Seatpost | OC Mountail Control MC20, 31.6mm, Dropper Type: Dropper |
| Pedals | VP-537 Black |
| Rear Derailleur | Shimano XT M8130 Link Glide SGS Shadow Plus |
|---|---|
| Crank | Alloy EP8 36t w/chainguard |
| Shifters | Shimano XT M8130 Link Glide |
| Cassette | Shimano CS-LG600 11-50t 11-Speed |
| Chain | Shimano LG500 |
| Brakes | Magura MT5 E-STOP Hydraulic Disc Easy Route Connection Type: Magura MT5 Hydraulic Disc |
| Rims | Race Face AR 30c Tubeless Ready |
|---|---|
| Tires | Schwalbe Johnny Watts, 29x2.35 RaceGuard Reflective Tape |
| Motor | Shimano EP8 |
|---|---|
| Battery | Orbea Internal 540Wh (Optional 252Wh Range Extender) |
| Remote | RS |
| Display | Shimano SC-EM800 |
| Charger | Orbea Smart Charger (42V-4A) |
| Lights | Front: Lezyne Super HB STVZO 1000 with Remote, Low Bean 600 Lumens, High Bean 1000 Lumens, Rear: Lezyne Super Bright CARRIER STVZO Alert Technology 12Lumen |
|---|---|
| Fenders | CURANA Apollo 70mm |
| Racks | Orbea Kemen Suv oversize Alloy Rear Carrier, w/Mik HD and Oertlieb QL3.1 system |
