2021 Orbea

RALLON M20

A 29″ carbon frame full suspension enduro bike with upper mid-range components.
Compare the full range

Manufacturer Price

$4,899
FrameCarbon
SuspensionFull, 160 / 170mm
ForkFox Performance Float 38
ShockFox Float DPX2 Performance
Wheels29″ Aluminum
Drivetrain1 × 12
GroupsetSLX, Race Face
BrakesHydraulic Disc
SeatpostDropper
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
RALLON M20
Other Enduro bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

28 mph

RALLON M20

26 mph

Similar Bikes

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full RALLON model range

View Comparison
Sizing
SM/MD

5'2" – 5'9"

LG

5'6" – 6'1"

XL

5'10" – 6'6"

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Reviews
Loam Wolf
2022 Enduro Shootout: Orbea Rallon

Nov 2022

This Orbea Rallon review dives deep into this bike’s performance since the 2022 overhaul. Read our review of this incredible bike!

Highs
  • Fast as F

  • Likes to get loose

  • Looks exotic

  • On board storage and tools

  • Prefers a coil

Lows
  • Can beat you up

  • Low BB

  • Stiff off the top suspension

Read Review

MBR
Orbea Rallon M-Team first ride review - MBR

Apr 2022 · Alan Muldoon

rbea The new Orbea Rallon will be ripping it up on the EWS circuit this year piloted by Martin Maes. We swung a leg over it to see how it stacks up against the best enduro bikes on sale now. Need to know Updated Rallon platform has moved with the times. Longer, lower and slacker. Geometry designed around a 170mm fork. Rear suspension delivers 160mm, where the progression rate has been increased to work with coil shock and larger volume air shocks like the Fox Float X2 Internal downtube storage has been added Three 29er options and one Mullet, but with MyO personalization it’s easy to customise your build Now available in four frame sizes Evolution of the Orbea Rallon It’s October 2013, and I’m wandering around Finale Ligure, Italy, in a daze. I can’t for the life of me remember why I was there. All I recall is Steve Jones from Dirt magazine asking me if I was attending the Orbea launch. I replied no, as MBR hadn’t been invited. I promptly became his plus one and the party got underway. The reason for the end of season festivities? Everyone was gathered to celebrate the launch of the new Rallon R4, a 160mm travel enduro bike with a revised suspension layout and 27.5in wheels. Well, it was almost 10 years ago. Well, it was almost 10 years ago Two things really struck me about that bike. The first was how good the low BB height felt as it increased stability and confidence. The second was how effective the suspension was – the combination of the custom tuned Bos Kirk shock, concentric rear axle pivot and longer shock link giving the bike unparalleled tracking and control. I left Finale impressed that the more traditional XC brand for the Basque country had produced such a formidable enduro race bike. Fast forward to 2017 and Orbea launched the next round of revisions, updates that include the switch to 29in wheels, a side-arm frame design, similar to, but not a copy of a Specialized, and a much shorter rocker link to actuate the shock. The low and lower BB heights remained, but the suspension feel had changed a lot on the Rallon R5, the bike less planted and plush, with a greater emphasis on pedalling performance. Obviously I wasn’t the only one that noticed the difference as Orbea then followed that up in 2019 with the Rally On linkage that boosted travel on the rear by 10mm to 160mm, and increased the progression rate from 8% to 20%. Frame and geometry So what’s new about the 2022 Rallon R6? The biggest differences are the updates that Orbea has made to the sizing and geometry. As such the BB height is a hair lower still, the reach numbers have grown on all four frame sizes and the seat tube heights have shrunk. In fact, Orbea has added 30mm to the reach on the size L, which brings it pretty much inline with the XL …Continue reading »

Highs
  • Updated sizing and geometry is on the money. Low BB height feels amazing on steeper, rowdy trails. The bike feels light and agile, with good compliance in the frame.

Lows
  • Needs a Double Down casing rear tyre. One and done OC multi-tool is all but useless. LockR downtube storage is tight on space.

Read Review

Vital MTB
2022 Orbea Rallon M-LTD Bike

Oct 2021 · BHowell

The one mountain bike, bike.

Highs
  • Pedaling efficiency

  • Easy to get along with

  • Versatility is the name of the game

  • Customizable builds

  • Urges riders to go faster

  • Not easily unsettled

Lows
  • Rear suspension could be a bit less harsh

  • The grips are hard and uncomfortable

Read Review

Beta
Orbea Introduces the New Rallon

Sep 2021 · Beta

Super. Enduro.

Read Review

Enduro Mountainbike Magazine
License to rip? The new 2022 Orbea Rallon in review

Sep 2021 · Peter Walker

We had the chance to test the new 2022 Orbea Rallon M-LTD and find out what the latest rig of the spanish bike (gun?) smiths is capable off.

Highs
  • Plush and active suspension with the coil shock

  • Clever frame details

  • Customisable look

  • Additional shock yoke for a mullet setup (included as standard)

Lows
  • Bike requires an experienced and active rider

Read Review

Pinkbike
First Look: 2022 Orbea Rallon - Now With In-Frame Storage

Sep 2021 · Mike Kazimer

The Rallon underwent the longer and slacker treatment, and also received a secret snack compartment.

Read Review

NSMB
Orbea Rallon M20 - First Impressions

Feb 2020

Uncle Dave puts on his engineer's pocket protector and decides the Rallon is the love child of ABP/Split Pivot and FSR...

Read Review

Bicycling
Orbea's Rallon Just Might be the Only Mountain Bike You'll Ever Need.

Aug 2019

The M-Team will blast a rocky descent and happily climb up and do it again.

Highs
  • Great Build

  • Solid Pedaling Platform

Lows
  • Sluggish dropper post

  • Odd sizing

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Orbea Monocoque Race Carbon. Advanced Dynamics 160mm suspension technology. 29" wheels.Concentric Boost 12x148 rear axle. Pure Enduro geometry. Internal cable routing. ISCG05

ColorsBlack (Matte) / Black-Purple (Gloss); Green (Matte) /Orange (Gloss); Grey Blue - Bright Red (Gloss)

Fork

Fox 38 Float Performance 170 Grip 3-Position QR15x110

Travel170mm

Spring TypeAir

Shock

Fox DPX2 Performance 3-Position Evol custom tune 230x60mm

Travel160mm

Headset

Acros Alloy 1-1/8 - 1-1/2" Integrated

Stem

OC1 3D Forged 35mm interface 7º

Handlebar

OC1 35mm 12mm Rise 780mm

Saddle

Fizik Taiga S-alloy rail

Seatpost

OC2 Dropper 31.6mm

TypeDropper

Groupset
Rear Derailleur

Shimano SLX M7100 SGS Shadow Plus

Crank

Race Face Aeffect 32t

Shifters

Shimano SLX M7100 I-Spec EV

Cassette

Shimano CS-M7100 10-51t 12-Speed

Chain

Shimano M6100

Brakes

Shimano M6120 Hydraulic Disc

TypeHydraulic Disc

Wheels
Rims

DT Swiss E-1900 Spline 30c TLR 15/110mm CL

Tires

Maxxis Minion DHR II 2.40" FB 60 TPI Dual Exo TR
