2021 Orbea AVANT H40-D

An aluminum frame endurance bike with mid-range components and mechanical disc brakes, priced in the middle of the AVANT model range. Compare the full range

View on orbea.com

2021 Orbea AVANT H40-D
MSRP$1,699
FrameAluminum
ForkCarbon
Wheels700c
Drivetrain2 × 10
GroupsetTiagra, FSA
BrakesMechanical Disc

Notify me when this bike becomes available or goes on sale.

Where to Buy
Compare

Gearing

2 × 10 — 20 speed

AVANT H40-D

39 mph

Similar Bikes

39 mph

The AVANT H40-D is easier to ride up hills than similar bikes.

The AVANT H40-D is geared about the same as similar bikes for riding downhill.


Estimated Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more. Learn more

Spec level →$0$200$400$600$800$1,000$1,200$1,400$1,600
This bike
Other endurance bikes

Reviews

July 2021

BikeRadar
Orbea Avant H60-D review

Ultra-distinctive, updated and integrated endurance bike

Read Full Review

March 2021

Cycling Weekly
Orbea Avant H60 Disc road bike

Perhaps the only bike at this price point with such an integrated cockpit – but is this where you should be spending your money?

Read Full Review

July 2020

Bikerumor
Orbea Avant all-road bike finds new life in affordable, fully integrated alloy frame

Orbea's all-day endurance alloy Avant mixes all-road capability with all-day comfort in the most affordable integrated cockpit road bike you'll find...

Read Full Review

February 2018

Road Bike Action
Orbea Avant M40

The Spanish marque evolves the endurance bike in our latest Orbea bike test

Read Full Review


Geometry

Sizing
47cm

5'1" – 5'4"

49cm

5'2" – 5'7"

51cm

5'4" – 5'9"

53cm

5'7" – 5'12"

55cm

5'10" – 6'2"

57cm

6'0" – 6'4"

60cm

6'2" – 6'10"


Specs
Build
Frame

Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1,5" ICR, BB 68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27,2mm, MMS system.

BB StandardBSA, 68mm, threaded

Fork

Orbea carbon fork 2021, aluminum steerer, 1-1/8" head tube

Bottom Bracket

BSA, 68mm, threaded

Headset

Acros Alloy 1-1/2" Internal Cable Routing

Stem

OC1 31.8mm interface -6º

Handlebar

OC1 Road, reach 80mm, drop 125mm

Saddle

Selle Royal Seta RS

Seatpost

Alloy 27.2 Offset 20

Groupset
Rear Derailleur

Shimano Tiagra 4700 GS

Front Derailleur

Shimano Tiagra 4700

Crank

FSA Omega Megaexo 34x50t

Shifters

Shimano Tiagra ST-4700

Cassette

Sun Race CSMS1 11-34t 10-Speed

Chain

KMC X10

Brakes

Tektro MD-C550 Mechanical Disc

Wheels
Rims

Orbea wheel: Cosra with 12mm E-Thru hubset Shimano RS470 28H

Tires

Vittoria Zafiro V Rigid bead 700x28c
