2020 Orbea
TERRA M20-D 1X
A carbon frame gravel bike with high-end components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
$3,299| Frame | Carbon |
|---|---|
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 1 × 11 |
| Groupset | GRX 800 |
| Brakes | Hydraulic Disc |
For This Bike
5'0" – 5'6"
5'4" – 5'9"
5'10" – 6'1"
6'2" – 6'4"
6'3" +
Nov 2018 · Matthew Page
A superb, customisable all-rounder that rides brilliantly on and off road, and is good value
Customisable paint finish and components
Compliant and comfortable rear end
Extra mounting options for added versatility
Narrow rims
Lack of front end comfort
Non-tubeless ready wheels
Sep 2018 · David Arthur @davearthur
A good choice for covering gravel and road quickly
Dec 2017
CyclingTips US technical editor James Huang's long-term review of the new Orbea Terra gravel bike.
Oct 2017 · Warren Rossiter
A very welcome departure from Orbea that’s smooth and speedy with sweet handling. Buy if you want to cover grit and gravel fast and don’t want to compromise your road rides too much either
Rapid off road, sweet handling and smooth on it
Some component compromises mean less value for money than some
| Frame | Orbea Terra carbon OMP disc, monocoque construction, tapered 1-1/8" - 1,5", PF30, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x P1.5, internal cable routing, EC/DC compatible, SP 27,2mm. BB Standard: PF30, Press Fit Colors: Yellow-Black; Anthracite Glitter (Gloss) / Black (Matte); Black-Bright Red (Matte) |
|---|---|
| Fork | Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system |
| Bottom Bracket | PF30, press-fit |
| Headset | FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings |
| Stem | OC2 Road -8º |
| Handlebar | OC1 All Road, reach 80mm, drop 125mm, flare 12º |
| Saddle | Selle Italia X3 Flow |
| Seatpost | OC2 27.2 Offset 20 Type: Rigid |
| Pedals | N/A |
| Rear Derailleur | Shimano RX812 GS Direct mount |
|---|---|
| Crank | Shimano GRX RX810 40t |
| Shifters | Shimano ST-RX810 |
| Cassette | Shimano XT M8000 11-40t 11-Speed |
| Chain | Shimano HG 601 |
| Brakes | Shimano ST-RX810 Type: Hydraulic Disc |
| Rims | FULCRUM Racing 900 DB |
|---|---|
| Tires | Vittoria Terreno Dry CX-Gravel G2.0 TNT 700x38c |
