2020 Orbea
CARPE 40
A 700c aluminum frame commuter bike with mid-range components and mechanical disc brakes.
Compare the full range
| Frame | Aluminum |
|---|---|
| Suspension | Rigid |
| Fork | Steel |
| Wheels | 700c Aluminum |
| Drivetrain | 1 × 7 |
| Groupset | Tourney, Shimano |
| Brakes | Mechanical Disc |
For This Bike
4'11" – 5'4"
5'2" – 5'8"
5'6" – 6'0"
5'10" – 6'4"
6'2" – 6'7"
Jan 2021 · Warren Rossiter
Fixed-gear-inspired, stripped-down speedster
Fun handling
High comfort from great contact points
Flex in the crank arms
Sluggish tyres
| Frame | Orbea Urban Speed, Aluminium 6000, Orbea Tube Shaping, Flat Mount Disc Brake, 135x9 QR, Carrier and Mudguard compatible, max 700x40C, Inner Cable routing, Tire Clearance: 40c Colors: White (Gloss) / Bright Red (Mate); Met. Navy Blue (Matte) / Purple (Gloss); Bright Red-Black (Matte-Gloss); Black (Matte-Gloss) |
|---|---|
| Fork | Speed 400mm Steel Post mount |
| Headset | 1-1/8" Semi-Integrated |
| Stem | Alloy 31.8 A:6º |
| Handlebar | Alloy 31.8mm Riser 640mm |
| Saddle | Velo 1221 |
| Seatpost | Alloy 27.2 Offset 0 Type: Rigid |
| Pedals | VP-538 Black |
| Rear Derailleur | Shimano TY-300 |
|---|---|
| Crank | Orbea Alloy 42t |
| Shifters | Shimano SL-M315 |
| Cassette | Shimano HG200 12-32t 7-Speed |
| Chain | KMC Z7 GYBR |
| Brakes | Shimano TX805 Mechanical Disc Type: Mechanical Disc |
| Brake Levers | Orbea Trekking Alloy 4-finger |
| Rims | Orbea Airline Corsa Disc 700X19c |
|---|---|
| Tires | Kenda K1067 700x38C Reflective type+puncture protection |
