2020 Orbea

CARPE 10

A 700c aluminum frame commuter bike with high-end components and hydraulic disc brakes.
Compare the full range

FrameAluminum
SuspensionRigid
ForkCarbon
Wheels700c Aluminum
Drivetrain1 × 10
GroupsetXT, Deore
BrakesHydraulic Disc
View on orbea.comLearn about Orbea
Add to Comparison
Shop with a Gear Advisor
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison

View more similar bikes →

Insights
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

33 mph

CARPE 10

31 mph

Similar Bikes

Highest gear

(descending)

Sizing
XS

4'11" – 5'4"

SM

5'2" – 5'8"

MD

5'6" – 6'0"

LG

5'10" – 6'4"

XL

6'2" – 6'7"

Rider Fit Notes
  • 6'3", size XL, Just right
View details
Reviews
BikeRadar
Orbea Carpe 40 review

Jan 2021 · Warren Rossiter

Fixed-gear-inspired, stripped-down speedster

Highs

  • Fun handling

  • High comfort from great contact points

Lows

  • Flex in the crank arms

  • Sluggish tyres

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Orbea Urban Speed, Aluminium 6000, Orbea Tube Shaping, Flat Mount Disc Brake, 135x9 QR, Carrier and Mudguard compatible, max 700x40C, Inner Cable routing,

Tire Clearance: 40c

Colors: White (Gloss) / Bright Red (Mate); Met. Navy Blue (Matte) / Purple (Gloss); Bright Red-Black (Matte-Gloss); Black (Matte-Gloss)

Fork

Speed 400mm Carbon Flat mount

Headset

1-1/8" Semi-Integrated

Stem

Orbea TDS-C301

Handlebar

Orbea AL320 Riser 680mm

Saddle

Velo 1221

Seatpost

Orbea C255 27.2x300mm

Type: Rigid

Pedals

VP-538 Black

Groupset
Rear Derailleur

Shimano XT M781 Shadow

Crank

Orbea Alloy 42t

Shifters

Shimano Deore M6000

Cassette

Shimano HG50 11-36t 10-Speed

Chain

KMC X10

Brakes

Shimano MT201 Hydraulic Disc

Type: Hydraulic Disc

Wheels
Rims

Orbea Airline Corsa Disc 700X19c

Tires

Kenda K1067 700x38C Reflective type+puncture protection

Accessories
Lights

Front: Joss Spanninga Kendo XDAS Dinamo, Rear: Spanninga Pixeo

Fenders

SKS EDGE Alloy C46R

Racks

Rear: Orbea rear luggage carrier (Max:18Kg)
