Today’s Deals2025 Mondraker
PRIME S
A 29″ aluminum frame fitness e-bike with modest components and sram hydraulic disc brakes.
Compare the full range
| Weight | 51.8 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Hardtail, 120mm |
| Fork | Steel |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | SRAM, e*thirteen |
| Motor | Bosch 600W 85Nm mid-drive |
| Battery | Bosch 800Wh |
| Brakes | SRAM Hydraulic Disc |
5'3" – 5'9"
5'6" – 5'11"
5'8" – 6'2"
5'10" – 6'4"
6'2" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Mar 2026 · Travis Reill
Mondraker updates the Prime e-bike platform with two Prime builds for trail riding and the Prime X for urban adventures
| Frame | Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, UDH, Hanger Standard: UDH Colors: Grey / Black; Desert / Black |
|---|---|
| Fork | RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload Travel: 120mm Spring Type: Air |
| Headset | Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock |
| Stem | Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore |
| Handlebar | Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise. |
| Saddle | Ergon SMC10 Gel |
| Seatpost | Onoff S3 0-R, diameter 31.6mm, length 400mm Type: Rigid |
| Grips | Onoff Beehive, 1lock-on, 135mm |
| Rear Derailleur | SRAM 70 Eagle, T-Type, 12s |
|---|---|
| Crank | E.13 Helix Core E*Spec Plus, All sizes: 160mm, Rings: SRAM Eagle 34T T-Type, direct mount, steel, CL55 |
| Shifters | SRAM Trigger 70, 12s, T-Type Actuation |
| Chain | SRAM 70 T-Type, 12s Flattop, PowerLock |
| Brakes | Front: SRAM DB6, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads, Rear: SRAM DB6, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads Type: SRAM Hydraulic Disc |
| Brake Levers | SRAM DB6, tool reach adjust, lever pivot bushings |
| Rims | WTB Sportterra Tough,6061 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes |
|---|---|
| Spokes | WTB Straight gauge spokes & black brass locking nipples |
| Front Hub | WTB Frequenzy Sport Boost 15x110mm, fully machined aluminum, IS 6 bolts |
| Rear Hub | WTB Frequenzy Sport Boost 12x148mm, fully machined aluminum, IS 6 bolts, HG freehub |
| Tires | Front: Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead, Rear: Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
| Motor | Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y) |
|---|---|
| Battery | Bosch Powertube 800Wh |
| Display | Purion 200 |
