Today’s Deals2022 Mondraker
PLAY 24
A 24″ aluminum frame mountain youth e-bike with upper mid-range components and sram level hydraulic disc brakes.
Compare the full range
| Weight | 33.3 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Hardtail, 100mm |
| Fork | RockShox Judy Silver TK |
| Wheels | 24″ Aluminum |
| Drivetrain | 1 × 11 |
| Groupset | NX |
| Motor | MAHLE hub-drive |
| Battery | MAHLE 250Wh |
| Brakes | SRAM Level Hydraulic Disc |
| Frame | Play 24 6061 Alloy Stealth Evo, hydroformed tubing, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible BB Standard: BSA, 73mm, Threaded Color: Black / Silver/red |
|---|---|
| Fork | RockShox Judy Silver TK 26, 100mm, TurnKey, Solo Air, tapered steerer tube, 9x100mm axle, 30mm steel stanchions, 40mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload Travel: 100mm Spring Type: Air |
| Bottom Bracket | Prowheel BSA, 73mm |
| Headset | ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º |
| Stem | ONOFF Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore |
| Handlebar | MDK XC 1.0, 6061 alloy, rise: 25mm, width: 580mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
| Saddle | SDG Fly JR |
| Seatpost | MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 300mm Type: Rigid |
| Grips | ONOFF Twin, 1lock-on, 135mm |
| Rear Derailleur | SRAM NX, 11s, long cage, X-actuation 1:1 |
|---|---|
| Crank | Prowheel, Direct mount chain ring, 127mm, Rings: 28T, steel |
| Shifters | SRAM trigger NX 11s, X-actuation 1:1 |
| Chain | SRAM PC1110 11s, Powerlock |
| Brakes | Front: SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad, Rear: SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad Type: SRAM Level Hydraulic Disc |
| Brake Levers | SRAM Level, tooled reach adjust, lever pivot bushings |
| Rims | MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes |
|---|---|
| Spokes | CN round stainless steel |
| Front Hub | Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts |
| Rear Hub | Mahle-Ebikemotion X-35 |
| Tires | Front: Kenda Booster 24x2.4 single compound 30TPI, wire bead, Rear: Kenda Booster 24x2.4 single compound 30TPI, wire bead |
| Motor | Mahle-Ebikemotion X-35 |
|---|---|
| Battery | Mahle-Ebikemotion Internal 250Wh |
| Display | Mahle-Ebikemotion |
