2019 Mondraker
Summum Pro
A 27.5″ aluminum frame full suspension downhill bike with high-end components.
Compare the full range
Manufacturer Price
$6,120| Weight | 36.8 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Full, 205 / 203mm |
| Fork | Fox Performance Elite Float 40 |
| Shock | Fox Float DHX2 Performance Elite |
| Wheels | 27.5″ Aluminum |
| Drivetrain | 1 × 10 |
| Groupset | Zee |
| Brakes | Hydraulic Disc |
For This Bike
5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | Aluminum |
|---|---|
| Fork | FOX 40 27.5 Float GRIP EVOL Performance Elite, air spring, 1-1/8” steerer tube, 20mm x 110mm axle. Settings: low-speed compression, low-speed rebound, air preload. Travel: 203mm Spring Type: Air |
| Shock | FOX DHX2 Performance Elite, 222mm x 70mm. Settings: low-speed compression, low-speed rebound, spring preload. S: 450lbs, M: 500lbs, L/XL: 550lbs Travel: 205mm Spring Type: Air |
| Bottom Bracket | Shimano 73mm |
| Headset | Onoff Mercurium 1.5 ZS, ACB sealed bearings, 56mm external diameter |
| Stem | Onoff Stoic DH Integrated FG, 20-30mm adjustable length, 31.8mm clamp, 6061 alloy |
| Handlebar | Mondraker double butted 6061 alloy, 25mm rise, 780mm width, 9º backsweep, 5º upsweep, 31.8mm clamp |
| Saddle | SDG I-Fly 2.0 I-Beam, high-density PU foam, Cordura sides |
| Seatpost | SDG Micro I-Beam SP-751 alloy, 300mm length, micro-adjustment Type: Rigid |
| Pedals | N/A |
| Grips | Onoff Diamond, lock-on, 130mm |
| Rear Derailleur | Shimano Zee RD-M640-SS, 10-speed, Shadow Plus technology, short cage |
|---|---|
| Front Derailleur | N/A |
| Crank | Shimano Zee M640, alloy, reinforced steel axle, 165mm length |
| Shifters | Shimano Zee SL-M640, 10-speed, 2-way release |
| Cassette | Shimano CS-HG500-10, 11-25 tooth, 10-speed |
| Chain | Shimano HG54, 10-speed |
| Chain Guide | e*thirteen LG1+, DMB (Direct Mount Bashguard) Gen 2 Stealth Idler, aluminum hardware, adjustable/replaceable lower armature, solvent-resistant polycarbonate, adjustable upper slider |
| Brakes | Shimano Zee M640, 4-piston caliper, RT66 203mm IS 6-bolt rotors, resin pads Type: Hydraulic Disc |
| Brake Levers | Shimano Zee, ergonomic anti-skid lever with servo wave, tool-free reach adjust |
| Rims | DT Swiss FR560 27.5, 30mm internal width, tubeless ready, 32-hole |
|---|---|
| Spokes | CN stainless steel butted 2.0-1.8-2.0 |
| Front Hub | Front: MDK Disc Pro DH, 20mm x 110mm, IS 6-bolt, Rear: MDK Disc Pro DH, 12mm x 150mm, sealed bearings, IS 6-bolt |
| Rear Hub | Front: MDK Disc Pro DH, 20mm x 110mm, IS 6-bolt, Rear: MDK Disc Pro DH, 12mm x 150mm, sealed bearings, IS 6-bolt |
| Tires | Maxxis Minion DHR II 27.5" x 2.4", Super Tacky compound, wire bead |
