2018 Merida

eBIG.TRAIL 800

A 27.5″ hardtail trail e-bike with high-end components.
Compare the full range

Weight45.6 lbs
SuspensionHardtail, 130mm
ForkRockShox Revelation RC
Wheels27.5″ Aluminum
Drivetrain1 × 11
GroupsetXT, SLX
MotorShimano 250W 70Nm mid-drive
BatteryShimano 500Wh
BrakesShimano SLX Hydraulic Disc
SeatpostDropper
View on merida-bikes.comLearn about Merida
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
eBIG.TRAIL 800
Other Trail bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

25 mph

eBIG.TRAIL 800

26 mph

Similar Bikes

Highest gear

(descending)

Sizing
SM

5'2" – 5'8"

MD

5'6" – 5'11"

LG

5'10" – 6'3"

XL

6'1" – 6'7"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Geometry
Specs
Build
Frame

eBIG.TRAIL

Fork

Rock Shox Revelation RC B SoloAir-130mm travel

Travel: 130mm

Spring Type: Air

Shock

N/A

Headset

FSA NO.55EP neck

Stem

Merida Expert SS, 45mm length

Handlebar

MERIDA EXPERT II 780mm, rise: 20 mm, dia: 35mm, 6°

Saddle

MERIDA Sport 5

Seatpost

MERIDA EXPERT Dropper 30.9mm

Type: Dropper

Pedals

VPE-537

Groupset
Rear Derailleur

Shimano XT M8000 Shadow+

Crank

Shimano CRE80-B 34

Shifters

Shimano SLX 11

Cassette

Shimano SLX, 11 speed, 11-46 teeth

Chain

KMC X11e

Chain Guide

N/A

Brakes

Shimano SLX hydraulic disc brakes with 203mm rotors

Type: Shimano SLX Hydraulic Disc

Brake Levers

attached

Wheels
Rims

MERIDA EXPERT TP

Spokes

Black stainless

Front Hub

15mm front hub, Shimano Deore, Boost standard centrelock rear

Rear Hub

15mm front hub, Shimano Deore, Boost standard centrelock rear

Tires

Maxxis Rekon 27.5"+ 2.8" folding

Electric Components
Motor

Shimano [E8000]

Battery

Shimano E8010 500Wh

Remote

Shimano SC-E8000, LCD color display showing color coded assist levels, time, battery status, speed, distance, total distance, riding time, estimated range, range overview, error messages, cadence, power input of rider in watts, and calorie consumption

Display

Shimano SC-E8000
