Today’s Deals2017 Merida
eBIG.TRAIL 800
A 27.5″ hardtail crosscountry e-bike with high-end components.
Compare the full range
| Suspension | Hardtail |
|---|---|
| Fork | RockShox Yari RC |
| Wheels | 27.5″ Aluminum |
| Drivetrain | 1 × 11 |
| Groupset | XT, SLX |
| Motor | Shimano 250W 70Nm mid-drive |
| Battery | Shimano 500Wh |
| Brakes | Shimano SLX Hydraulic Disc |
| Seatpost | Dropper |
5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | eBIG.TRAIL (STePS) BB Standard: STEPS, Press Fit |
|---|---|
| Fork | RockShox FS YARI RC 27.5"+ BOOST Spring Type: Air |
| Bottom Bracket | STEPS, press-fit |
| Handlebar | MERIDA EXPERT 35 760 |
| Saddle | MERIDA Sport 5 |
| Seatpost | MERIDA EXPERT Dropper 30.9 Type: Dropper |
| Rear Derailleur | Shimano XT GS Shadow+ |
|---|---|
| Crank | Shimano CRE80-B 34, SM-CDE 80 Chainguide |
| Shifters | Shimano SLX 11 |
| Cassette | Shimano XT 11-46 11s |
| Chain | KMC X11 |
| Brakes | Shimano SLX ice Type: Shimano SLX Hydraulic Disc |
| Brake Levers | attached |
| Rims | MERIDA Expert TP |
|---|---|
| Spokes | Black stainless |
| Front Hub | Shimano Deore boost cen |
| Rear Hub | Shimano Deore boost cen |
| Tires | Maxxis Rekon 27.5+ 2.8 fold |
| Motor | Shimano DU-E8000 |
|---|---|
| Battery | Shimano E8010 500Wh |
| Display | Shimano Cyclo display SC-E8000 |
| Lights | battery lamp |
|---|
First added October 11
Last updated October 11
Not listed for 2,787 days
