Today’s Deals2025 Megamo
FLAME AL 03
A 29″ aluminum frame full suspension enduro e-bike with high-end components.
Compare the full range
Manufacturer Price
€6,999($8,143)| Frame | Aluminum |
|---|---|
| Suspension | Full, 160 / 160mm |
| Fork | Fox Float 38 |
| Shock | Fox Float X Factory |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | XT |
| Motor | Bosch 750W 100Nm mid-drive |
| Battery | Bosch 800Wh |
| Brakes | Shimano XT Hydraulic Disc |
| Seatpost | Dropper |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full FLAME model range
View Comparison5'2" – 5'7"
5'6" – 5'11"
5'9" – 6'2"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | Full Integratted Battery, Aluminium 6061, 12x148 Boost, Horst Link 4, Wheel travel: 160 mm BB Standard: Bosch, Press Fit Colors: Green; Forest; Black |
|---|---|
| Fork | FOX 38 Kashima, FLOAT, 29in, 160mm, Grip X2, HSC, LSC, HSR, LSR, 15QRx110, 1.5 T, 68HT, 44mm Rake Travel: 160mm Spring Type: Air |
| Shock | Fox Float X, Factory-Series, Kashima, 2pos-Adj, Evol LV, 230x60 Travel: 160mm |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros AZX-589 ZS56 blocklock 150º |
| Stem | Race Face Aeffect R / S size 35 x 50 mm / M size 35 x 50 mm / L size 35 x 70 mm |
| Handlebar | Race Face Turbine R, 35 x 800 x 20 mm |
| Saddle | Selle San Marco Ground Short Open-fit Titanium |
| Seatpost | Fox Transfer Kashima 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 175 mm Drop Type: Dropper |
| Rear Derailleur | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
|---|---|
| Crank | FSA Bosch Direct Mount Chainring 34t CL55 12-Speed, Crankset 320 165mm |
| Shifters | Shimano XT M8100, 12-Speed |
| Cassette | Shimano XT M8100 10-51T |
| Brakes | Shimano XT BR-M8220, hydraulic disc 4-Piston, 203/203mm Type: Shimano XT Hydraulic Disc |
| Rims | DT Swiss M 1900 SP, 30mm Tubeless ready Aluminium rim |
|---|---|
| Front Hub | DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| Rear Hub | DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| Tires | Maxxis Front: 29 x 2.5 Assegai, Rear: 29 x 2.4 Minion DHR II |
| Motor | Bosch Performance Line CX, 5gen BDU384Y, Smart System / 100Nm 750W |
|---|---|
| Battery | Bosch PowerTube 800 |
| Display | Bosch Purion 200 |
