Pine Mountain 1
A 27.5″ steel frame hardtail trail bike with upper mid-range components.
Compare the full range
MSRP | $1,299 |
---|---|
Frame | Steel |
Suspension | Hardtail, 120mm |
Fork | RockShox Recon Silver RL |
Wheels | 27.5″ Aluminum |
Drivetrain | 1 × 11 |
Groupset | SLX |
Brakes | Hydraulic Disc |
For This Bike
Aug 2020 · McCoy
Overall, Marin did a great job targeting the adventure bike rider and...
Jun 2020 · Logan Watts
The 2020 Pine Mountain 2 is an affordable bikepacking-specific trail hardtail with a record number of threaded eyelets. Here's the full review…
A happy-medium geometry that offers a snappy feel on the trail, solid climbing prowess, and a fairly stable ride
Built around 29 x 2.6” tires
Unbelievable amount of bosses and a downloadable diagram for making a custom frame bag
Well-priced as an entry level bikepacking bike, but there are a few needed upgrades
Vee Flow Snap tires are horrible and dangerous
Geometry misses the ideal mark with a reach that’s a little too short
Not as compliant as the older model
Heavy build with few disappointing components; handlebar is too stiff and fork is just okay
Mar 2020 · Pat Donahue
The redesigned Marin Pine Mountain 2 is a supremely versatile bike that is comfortable in many situations. This steel bicycle was designed with a clear...
Sep 2017
It's rare for a bike under 2K catches our eye but the Marin Pine Mountain 1 has much to offer at $700 under that mark...
Dec 2016 · Alan Muldoon
The Marin Pine Mopuntain rides more like an adventure bike than a trail hardtail designed to get your pulse racing.
Steel frame absorbs vibrations
Geometry needs a refresh
Apr 2016
A new hub standard is coming and it’s going to make beginner and intermediate bikes better. Here’s what you need to know. - Mtbr.com
Feb 2016 · Tom Marvin
You'll need razor-sharp skills to get the Pine Mountain rolling at serious speeds, but it's got no shortage of simple charm. Buy if you want a refreshingly straightforward steed for savouring cross-country excursions rather than bombing trails
Appealing retro simplicity, lively character, excellent as an adventure bike
Geometry and rigid setup mean only the most skilful riders will want to cane it on the pine mountain, quick-release wheels detract from handling accuracy
Frame | Series 2 Double Butted CrMo, 27.5+ Wheels, Boost 141x9mm Open Dropout, 73mm Threaded BB BB Standard: BSA, 73mm, Threaded |
---|---|
Fork | RockShox Recon RL 27.5+, 120mm Travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Lite, 51mm Offset Travel: 120mm Spring Type: Air |
Shock | N/A Spring Type: Air |
Bottom Bracket | External Sealed Cartridge Bearings |
Headset | FSA Orbit ITA, Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
Stem | Marin 3D Forged Alloy, 60mm |
Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 780mm Width, 4º Up, 9º Back |
Saddle | Marin MTB |
Seatpost | Marin Alloy Light Type: Rigid |
Pedals | Nylon Platform |
Grips | Marin Single Clamp Locking |
Rear Derailleur | Shimano SLX GS Shadow Plus 11-Speed |
---|---|
Front Derailleur | - - - |
Crank | Marin Forged Alloy 1x11, Hollow Spindle, Direct Mount Steel Forged Narrow-Wide 30T Chainring, Boost Spacing |
Shifters | Shimano SLX Deore 1x11 Speed |
Cassette | SunRace 11-Speed, 11-42T |
Chain | KMC X11L |
Chain Guide | N/A |
Brakes | Shimano MT501 Hydraulic Disc, 180mm Rotor Type: Hydraulic Disc |
Brake Levers | Shimano MT501 Hydraulic |
Rims | Marin Aluminum Double Wall, 38mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible |
---|---|
Spokes | 14g Black Stainless Steel |
Front Hub | Joytech, 110x15mm, 6-Bolt Disc, 32H |
Rear Hub | Joytech, 141x9mm, 6-Bolt Disc, 32H |
Tires | Vee Tire, Crown Gem 27.5x2.8", Dual Control Compound, Folding Bead, Tubeless Compatible |
Last updated September 11
Not listed for 1,289 days
