2019 Marin

Nail Trail E1

A 27.5″ aluminum frame hardtail trail e-bike with upper mid-range components.
Compare the full range

MSRP$3,499
FrameAluminum
SuspensionHardtail, 140mm
ForkRockShox Recon Silver RL
Wheels27.5″ Aluminum
Drivetrain1 × 10
GroupsetDeore
MotorShimano 250W 70Nm mid-drive
BatteryShimano 500Wh
BrakesHydraulic Disc
SeatpostDropper
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
Nail Trail E1
Other Trail bikes
Sizing
SM

5'4" – 5'8"

MD

5'6" – 5'11"

LG

5'9" – 6'1"

XL

5'11" – 6'3"

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Reviews
BikeRadar
Marin Nail Trail 7 29er review

Aug 2016 · Guy Kesteven

Smart spec choices and well-thought out geometry make for a light and fast hardtail that can cut it down heavyweight trails. Buy if you're looking for a lightweight 29er hardtail that's excellent value and can handle even heavyweight trails

Highs
  • Lightweight, smooth, aggro-angled hardtail frame with high volume, high control wheelset. Excellent value tough trail spec

Lows
  • You might want a grippier rear tyre for winter (but you’ll love the speed in summer). A smooth, high volume 29er hardtail still isn’t as impact ignorant as a full-sus bike

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Series 3 E 6061 Aluminum, 27.5+ wheels, Post Mount Disc Specific Forged Dropouts, 148x12mm Thru-axle

Fork

RockShox Recon RL 27.5+, 140mm Travel, Compression and Rebound Adjustment, Solo Air Spring, 110x15mm Boost Spacing, Maxle Stealth, 51mm Offset

Travel140mm

Spring TypeAir

Shock

N/A

Spring TypeAir

Headset

FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

Stem

Marin 3D Forged Alloy, 35mm

Handlebar

Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 4º Up, 9º Back

Saddle

Marin Speed Concept

Seatpost

TranzX YSP18 Dropper Post, 120mm of Travel

TypeDropper

Pedals

Nylon Platform

Grips

Marin Dual Density

Groupset
Rear Derailleur

Shimano Deore Shadow Plus Direct Mount 10-Speed

Crank

Marin Forged Alloy, Steel Narrow-Wide 38T Chainring

Shifters

Shimano Deore

Cassette

SunRace, 10-speed, 11-46 tooth

Chain

KMC X10

Chain Guide

N/A

Brakes

Shimano BR-MT201 Hydraulic Disc, 203mm Rotor

TypeHydraulic Disc

Brake Levers

Shimano BR-MT201

Wheels
Rims

Marin Aluminum Double Wall, 38mm Inner, Pinned Joint, Disc Specifc, Tubeless Compatible

Spokes

14g Black Stainless Steel

Front Hub

Forged Alloy, 110x15mm, Centerlock Disc, 32H

Rear Hub

Forged Alloy, 148x12mm, Quad Sealed Bearings, Centerlock Disc, 32H.

Tires

Vee Tire, Crown Gem 27.5x2.8", Dual Control Compound, Synthesis Sidewall, Folding Bead, Tubeless Compatible

Electric Components
Motor

Shimano STEPS E8000

Battery

Shimano E8010, 500Wh

Recycling Program♻️ Call2Recycle

Rider Notes
