2025 KTM

MACINA GRAN 820

A 29″ aluminum frame hardtail crosscountry e-bike with upper mid-range components.
Compare the full range

Manufacturer Price

€4,299($5,002)
FrameAluminum
SuspensionHardtail, 80mm
ForkSuntour XCM
Wheels29″ Aluminum
Drivetrain1 × 10
GroupsetDeore
MotorBosch 600W 85Nm mid-drive
BatteryBosch 800Wh
BrakesTektro Hydraulic Disc
SeatpostDropper
View on ktm-bikes.atLearn about KTM
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
MACINA GRAN 820
Other Crosscountry bikes
Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full MACINA GRAN model range

View Comparison
Sizing
SM

5'2" – 5'8"

MD

5'6" – 5'11"

LG

5'10" – 6'3"

XL

6'1" – 6'7"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Geometry
Specs
Build
Frame

Macina Trekking Onroad Alloy 6061 PT800 Bosch BDU38 / T-5940

BB Standard: Bosch, Press Fit

Fork

Suntour XCM 32 ATB coil 29" NLO 80mm taper

Travel: 80mm

Spring Type: Coil

Bottom Bracket

Bosch, press-fit

Headset

Acros headsetcover OD62 Phyton

Stem

KTM Line adjust. 0-60° ICR

Handlebar

Ergotec Lady Town 630mm

Saddle

Selle Royal Lookin 3D

Seatpost

KTM Line dropper + suspension 30.9 T:100

Type: Dropper

Pedals

Trekking-Pedal VP-616 anti-slip

Grips

Ergon GP1 SD

Groupset
Rear Derailleur

Shimano Deore M4120-10 SGS shadow

Crank

KTM E-COMP ISIS 170mm Q16

Shifters

Shimano Deore M4100-10 display

Cassette

Shimano Deore M4100-10 / 11-42

Chain

KMC e10 EPT e-bike

Chain Guide

KTM type 9 for Bosch BDU38

Brakes

Tektro HD-T390 / E390 2-Piston

Type: Tektro Hydraulic Disc

Wheels
Rims

KTM Line - Shimano Deore M6000 CL 32H 100-5QR, Ryde Rival30 32H 622x30C, DT Champion 2.0 black \ KTM Line - Shimano Deore M6000 CL 32H 135-5QR, Ryde Rival30 32H 622x30C, DT Alpine II 2.34 black

Tires

Front: Schwalbe Al Ground Perf. RaceGuard 60-622 Reflex, Rear: Schwalbe Al Ground Perf. RaceGuard 60-622 Reflex

Electric Components
Motor

Bosch PERFORMANCE CX BDU3840 - 25km/h / 85Nm

Battery

Bosch PowerTUBE 800Wh horizontal

Display

Bosch LED remote / Bosch INTUVIA LCD Display

Accessories
Fenders

SKS A69R PET Trek 28" rear

Racks

KTM light 60 (snap-it 1.0)
