2025 KTM
MACINA CROSS CX 625

A 700c aluminum frame hybrid e-bike with modest components and shimano hydraulic disc brakes.
Compare the full range

Manufacturer Price

€3,599($4,125)

Where to Buy

Similar Bikes

Top Comparison

Insights

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full MACINA CROSS model range

Sizing

5'2" – 5'7"

5'6" – 5'11"

5'9" – 6'2"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Geometry

Specs

Build

Frame	Macina PTS Offroad 27.5" Al 6061; PT625Wh Bosch Gen.4/T-1270 BB Standard: Bosch, Press Fit
Fork	Suntour NX1 coil LO 63mm Travel: 63mm Spring Type: Coil
Bottom Bracket	Bosch, press-fit
Headset	KTM TEAM Trekking 1.1/8"-1.5" angle limit
Stem	KTM COMP 17°
Handlebar	KTM COMP low rizer 640mm
Saddle	Selle Royal Essenza Athletic
Seatpost	KTM COMP 30.9/300 Type: Rigid
Pedals	MTB-Pedal VP-195E alloy
Grips	KTM COMP Ergo Lock

Groupset

Rear Derailleur	Shimano Acera M3020-8 SGS
Crank	KTM E-COMP ISIS 170mm Q16
Shifters	Shimano Altus M315-8 display
Cassette	Shimano HG400-8 / 11-40
Chain	Shimano HG40-8
Brakes	Shimano MT200 / MT200 2-Piston Type: Shimano Hydraulic Disc

Wheels

Rims	KTM Line - Shimano Deore M6000 CL 32H 100-5QR, Ryde Rival Sport 32H 622x25C, DT Champion 2.0 black \ KTM Line - Shimano Deore M6000 CL 32H 135-5QR, Ryde Rival Sport 32H 622x25C, DT Alpine II 2.34 black
Tires	Front: Schwalbe Smart Sam SBC K-Guard 47-622 Reflex, Rear: Schwalbe Smart Sam SBC K-Guard 47-622 Reflex

Electric Components

Motor	Bosch PERFORMANCE CX BDU3741 - 25km/h / 85Nm
Battery	Bosch PowerTUBE 625Wh horizontal
Display	Bosch PURION 200 Display & Remote

Rider Notes
