2025 KTM

MACINA CHACANA 892 LFC

A 27.5″ aluminum frame full suspension trail e-bike with mid-range components.
Compare the full range

Manufacturer Price

€5,299($6,041)
FrameAluminum
SuspensionFull, 130mm front
ForkSuntour XCR Air
ShockFox
Wheels27.5″ Aluminum
Drivetrain1 × 11
GroupsetCUES
MotorBosch 600W 85Nm mid-drive
BatteryBosch 800Wh
BrakesShimano Deore Hydraulic Disc
SeatpostDropper
View on ktm-bikes.atLearn about KTM
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
MACINA CHACANA 892 LFC
Other Trail bikes
Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full MACINA CHACANA model range

View Comparison
Geometry
Specs
Build
Frame

Macina Chacana Al 6061 SLL 125 UDH PT800 Bosch BDU38/M5290

BB Standard: Bosch, Press Fit

Hanger Standard: UDH

Fork

Suntour XCR34X Air 27,5" 2CR 130mm taper

Travel: 130mm

Spring Type: Air

Shock

FOX Float Rhythm 2Pos 230x57,5

Bottom Bracket

Bosch, press-fit

Headset

Acros AICR internal 1.1/8"-1.5" angle limit

Stem

KTM TEAM Trail35

Handlebar

KTM COMP Trail35 rizer15 760mm

Saddle

Selle Royal Lookin Athletic Evo

Seatpost

KTM COMP II dropper internal 34.9 T:125

Type: Dropper

Pedals

MTB-Pedal flat VPE-527 alloy

Grips

Ergon GA30

Groupset
Rear Derailleur

Shimano CUES U6000-11/10 LG shadow+

Crank

KTM E-TEAM2 ISIS 170mm Q8

Shifters

Shimano CUES U6000-11 display

Cassette

Shimano LG400-11 / 11-50

Chain

KMC e11 Sport EPT e-bike

Brakes

Shimano Deore M6100 / M6120 4-Piston

Type: Shimano Deore Hydraulic Disc

Wheels
Rims

Mavic E-Crossride 27 CL 110x15TA|584x30TSS TLR \ Mavic E-Crossride 27 CL 148/12TA|584x30TSS HG TLR

Tires

Front: Schwalbe Johnny Watts Perf. Folding DD 65-584 Reflex, Rear: Schwalbe Johnny Watts Perf. Folding DD 65-584 Reflex

Electric Components
Motor

Bosch PERFORMANCE CX BDU3840 - 25km/h / 85Nm

Battery

Bosch PowerTUBE 800Wh horizontal

Display

Bosch LED remote / Bosch INTUVIA LCD Display

Accessories
Fenders

Racktime Alu 72mm B&M Xeltec

Racks

Racktime Alumee rails (plattform option)
