Name: 2016 Kona Esatto DDL
Brand: Kona
Rating: 4.44 (1 reviews)

Front: Continental Gran Sport Race 700x28c, Rear: Continental Gran Sport Race 700x28c

Ride deeper into road on the Esatto DDL’s brand new Kona SuperLight 7046 Aluminum Butted Alloy frame. With size-specific tubing incorporated to provide frames that are stiff enough for larger riders and compliant enough for smaller riders, along with a carbon Kona Road Endurance flat disc mount specific fork, fender readiness and sturdy front and rear dropouts, the Esatto DDL can take anything the never-ending road can throw at it.
Frame Features:
Our Esatto frames are highlighted by Kona Endurance Geometry, designed for comfort, stability, confidence and versatility. Featuring new light and lively Kona SuperLight 7046 Aluminum Butted alloy for 2016, the Esatto platform incorporates taller head tubes and shorter top tubes than more race-oriented road bikes. It has slacker angles, lower BB, and longer chainstays and wheelbase for stability, as well as a tapered head tube and steerer, with ample tire and fender clearance with flat disc mounts on the Esatto DDL. New for 2016, 15 x 100mm front and 12 x 142mm rear thru-axle systems have been added for stiffness.

Kona Esatto DDL

49cm

52cm

54cm

56cm

58cm

61cm

An aluminum frame endurance bike with high-end components and shimano hydraulic disc brakes.

We've tested the Esatto Disc, a do-it-all bike from a brand better known for its mouton bikes than its road bikes. But how does Kona's MTB nous translate to its on-road experience?

Frame	Aluminum
Fork	Carbon
Wheels	700c Aluminum
Drivetrain	2 × 11
Groupset	Ultegra, 105
Brakes	Shimano Hydraulic Disc

Frame	Kona SuperLight Aluminum Butted 7046
Fork	Kona Carbon Road Disc
Shock	n/a
Bottom Bracket	Shimano R600
Headset	FSA No.42/ACB
Stem	Kona Road Light
Handlebar	Kona Road
Saddle	Kona Road
Seatpost	Kona Road w/Offset Type: Rigid
Pedals	n/a
Grips	Kona Cork Tape

Rear Derailleur	Shimano Ultegra
Front Derailleur	Shimano 105
Crank	34/50t
Shifters	Shimano RS505 Hydraulic
Cassette	Shimano 105 11-32t 11spd
Chain	KMC X11
Chain Guide	n/a
Brakes	Shimano RS505 Hydraulic Type: Shimano Hydraulic Disc
Brake Levers	Shimano RS505 Hydraulic

Rims	Novatech Road 30 Disc Wheelset
Spokes	Novatech Road 30 Disc Wheelset
Front Hub	Novatech Road 30 Disc Wheelset
Rear Hub	Novatech Road 30 Disc Wheelset
Tires	Front: Continental Gran Sport Race 700x28c, Rear: Continental Gran Sport Race 700x28c
Disc Rotors	Shimano 140mm
