Today’s Deals2025 Kavenz
VHP G2 16
A 16″ full suspension trail frameset with mechanical disc brakes.
| Weight | 7.5 lbs (frame) |
|---|---|
| Suspension | Full, 120mm rear |
| Wheels | 16″ |
| Drivetrain | Internally Geared Hub |
| Brakes | Mechanical Disc |
Sep 2024 · Emptyagency
The VHP G2 is compatible with both the Pinion and Effigear Mimic systems.
| Fork | 160-180 for VHP16 - Crown to Axle 567-591mm (Geometry is designed with 581 ATC) |
|---|---|
| Shock | Trunnion 185/47,5 / 205x60 / 205x65 / 225x75 Mounting hardware: 22x8mm Travel: 120mm |
| Bottom Bracket | Pinion / Effigear Mimic Mount |
| Headset | ZS44/28.6 | ZS56/40 (for Tapered Forks) |
| Seatpost | 31.6 mm with internal seatpost cable routing Type: Rigid |
| Brakes | IS 2000 Type: Mechanical Disc |
|---|
First added October 25
Last updated June 13
