2019 Intense
M16 PRO
A 27.5″ carbon frame full suspension downhill bike with ultra high-end components.
| MSRP | $4,999 |
|---|---|
| Frame | Carbon |
| Suspension | Full, 240 / 200mm |
| Fork | RockShox BoXXer |
| Shock | RockShox Super Deluxe Coil |
| Wheels | 27.5″ Aluminum |
| Drivetrain | 1 × 7 |
| Groupset | X01, Truvativ Descendant |
| Brakes | Hydraulic Disc |
For This Bike
5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Mar 2016
In an effort to bring its top end downhill bike to the masses, Intense Cycles has released the M16 Carbon Expert Edition, which sells for $5899. - Mtbr.com
Jan 2016 · Sjones
One of the original innovators of DH works-bikes goes carbon
Jan 2016 · McCoy
We’ve only begun the long-term test period for this race rocket
| Frame | M16 275 Optimized Layup Carbon Front and Rear Triangle 275” DH Frameset, ISCG 05 Mount, w/ 157 x12 mm spacing, 215 -240 mm travel BB Standard: BSA, 83mm, Threaded Color: Gloss Red / Black |
|---|---|
| Fork | Rock Shox Boxxer World Cup, 200mm, Gloss Black, 20x110mm Travel: 200mm Spring Type: Air |
| Shock | Rock Shox Super Deluxe Coil World Cup, 250x75mm (SM - 400lb Spring, MD – 450lb Spring, LG – 500lb Spring, XL – 550lb Spring) Travel: 240mm Spring Type: Air |
| Bottom Bracket | BSA (threaded), 83 mm |
| Headset | Cane Creek, 40, alloy cartridge, 25 mm of spacers |
| Stem | Renthal Integra II Direct Mount 45 mm |
| Handlebar | Intense Recon DH Alloy 31.8mm – 800mm |
| Saddle | WTB Volt Team |
| Seatpost | Intense Recon DH Alloy, 31.6mm Type: Rigid |
| Grips | Intense Dual Density Lock-On |
| Rear Derailleur | SRAM X01 DH, 7 speed |
|---|---|
| Front Derailleur | N/A |
| Crank | TruVativ Descendant DH, GXP 83mm, 165mm, 36T |
| Shifters | SRAM X01 DH, 7 speed |
| Cassette | SRAM XG-795 10-24, 7 speed |
| Chain | SRAM X1, 11 speed |
| Chain Guide | E13 LG1 |
| Brakes | Shimano Saint, 203 mm front and rear Type: Hydraulic Disc |
| Rims | DT Swiss FR 1950 |
|---|---|
| Spokes | DT Swiss |
| Front Hub | DT Swiss FR 1950 CLASSIC 27.5, 110x20 mm front HUB; 157 x 12 mm rear w/XD Driver, 20 mm front |
| Rear Hub | DT Swiss FR 1950 CLASSIC 27.5, 110x20 mm front HUB; 157 x 12 mm rear w/XD Driver, 20 mm front |
| Tires | Front: 27.5x2.5, MINION DHF, FOLDABLE, F60, DH Casing, 3CG, Rear: 27.5X2.4, MINION DHR II, FOLDABLE, F60, DH Casing, 3CG |
