2019 Felt

BROAM 30

An aluminum frame gravel bike with upper mid-range components and hydraulic disc brakes.
Compare the full range

MSRP$1,899
Weight23.8 lbs
FrameAluminum
SuspensionRigid
ForkCarbon
Wheels700c Aluminum
Drivetrain2 × 11
Groupset105, FSA
BrakesHydraulic Disc
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Insights
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

36 mph

BROAM 30

36 mph

Similar Bikes

Highest gear

(descending)

Sizing
47cm

4'11" – 5'7"

51cm

5'5" – 5'9"

54cm

5'7" – 5'11"

56cm

5'9" – 6'2"

58cm

6'0" – 6'4"

61cm

6'1" – 6'6"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Felt Adventure Road Disc Superlite custom butted aluminum, smooth welded construction, BSA threaded 68mm bottom bracket shell, 12 x 142mm with Syntace style thru axle, flat mount disc brake standard, replaceable rear derailleur hanger, internal mechanical cable routing Shock:

BB StandardBSA, 68mm, Threaded

Fork

Felt Adventure Gravel UHC Advanced carbon fiber monocoque construction, ControlTaper 1.125" - 1.5" aluminum steerer tube, flat mount disc standard, 12 x 100mm thru axle with mid-mount rack and fender mounts

Bottom Bracket

FSA external cup, BSA threaded, 68mm

Headset

FSA integrated sealed cartridge bearing with Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), Felt top cap and aluminum bolt, No.42, 1.125 - 1.5"

Stem

Devox VariableAngle, ±8°/±16° rise, Ø31.8mm, 47cm: 80mm, 51cm: 90mm, 54 - 56cm: 100mm, 58cm: 110mm, 61cm: 120mm

Handlebar

Devox adventure bend, 86mm reach, 130mm drop, Ø31.8mm, 47 - 50cm: 420/450mm, 53 - 60cm: 440/470mm

Saddle

SR Essenza Blackstar Gel

Seatpost

Devox Lite Road, Ø27.2mm x 330mm length

TypeRigid

Groupset
Rear Derailleur

Shimano 105 R7000 11-speed short cage

Front Derailleur

Shimano 105 R7000 clamp-on, Ø31.8mm

Crank

FSA Omega Adventure Mega Exo, 46/30T, 47cm: 165mm, 51cm: 170mm, 54 - 56cm: 172.5mm, 58 - 61cm: 175mm

Shifters

Shimano 105 ST-R7020, 11-speed

Cassette

Shimano 11-speed, 11-34T

Chain

Shimano 11-speed

Brakes

Shimano 105 BR-R7070 hydraulic disc, 160mm rotor

TypeHydraulic Disc

Brake Levers

Shimano 105 ST-R7020, hydraulic

Wheels
Rims

Devox Adventure 2.1 Disc, tubeless compatible 21mm inner width, 23mm depth

Spokes

2.0mm stainless steel

Front Hub

Devox GR.2 Disc, sealed cartridge bearing, 12 x 100mm thru axle, Centerlock, 28H

Rear Hub

Devox GR.1 Disc, 11-speed, 12 x 142mm thru axle, Centerlock, 28H

Tires

Maxxis Refuse with Max Shield, tubeless ready, folding, 700 x 40c
