2017 Felt
FR30
An aluminum frame race bike with upper mid-range components and rim brakes.
Manufacturer Price
$1,499| Weight | 20.3 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 11 |
| Groupset | 105 |
| Brakes | Rim |
For This Bike
4'11" – 5'7"
5'5" – 5'9"
5'7" – 5'11"
5'9" – 6'2"
6'0" – 6'4"
6'1" – 6'6"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | Felt Race Road SuperLite Custom Butted 6061 aluminum, Dynaform TIG-welded construction, BB386 bottom bracket shell, replaceable rear derailleur hanger BB Standard: BB86/BB92, Press Fit |
|---|---|
| Fork | Felt Race Road UHC Advanced carbon fiber monocoque construction, size specific ControlTaper carbon fiber steer tube, crown race, crown, blades and dropouts |
| Shock | n/a |
| Bottom Bracket | Token For BB386 Frame with Shimano Crankset |
| Headset | 43 - 47cm: FSA IS-21 integrated, 1.125"" sealed cartridge bearing ; 51 - 54cm: FSA NO.382, 1.125""- 1.25"" sealed cartridge bearing; 56 - 61cm: FSA NO.38/42, 1.125"" - 1.5"" sealed cartridge bearing ; with Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), 1 x 10mm + 2 x 5mm PC headset spacers, Felt carbon fiber top cap and aluminum bolt |
| Stem | Felt VariableAngle, ± 8°/16° rise, Ø31.8mm 43cm = 70mm 47cm = 80mm 51cm = 90mm 54 - 56cm = 100mm 58=110mm 61=120mm |
| Handlebar | Felt Ergonomic SL Road, short 65mm reach, 125mm drop, Ø31.8mm 43 - 47cm = 380mm 51cm = 400mm 54 - 56cm = 420mm 58 - 61cm = 440mm |
| Saddle | Prologo Nago Evo PAS T2.0 |
| Seatpost | Felt UHC Performance carbon fiber, Ø27.2mm, 300mm length Type: Rigid |
| Pedals | N/A |
| Grips | Felt VelvetGel Tape with 3M Reflective Base |
| Rear Derailleur | Shimano 105 short cage |
|---|---|
| Front Derailleur | Shimano 105 clamp-on, Ø34.9mm |
| Crank | Shimano 105 43 - 47cm = 165mm 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm |
| Shifters | Shimano 105 |
| Cassette | Shimano 11-speed, 11-28T |
| Chain | Shimano HG600, 11-speed |
| Chain Guide | N/A |
| Brakes | Dual pivot caliper Type: Rim |
| Brake Levers | Shimano 105 |
| Rims | Felt Road RSL3 (tubeless ready), 22mm Width, 28mm Depth |
|---|---|
| Spokes | 2.0mm stainless steel |
| Front Hub | Felt R3, sealed bearing, 28H |
| Rear Hub | Felt R3, sealed cartridge bearing, 28H, 11-speed compatible |
| Tires | Schwalbe DURANO RaceGuard, 700c x 25c |
| Fenders | n/a |
|---|
