2020 Dartmoor

Hornet 26

A 26″ aluminum frame hardtail dirt jump bike with mid-range components.
Compare the full range

Weight30.3 lbs
FrameAluminum
SuspensionHardtail, 130mm
ForkManitou Circus Expert
Wheels26″ Aluminum
Drivetrain1 × 9
GroupsetX4, X5
BrakesHydraulic Disc
Learn about Dartmoor
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Insights
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

23 mph

Hornet 26

20 mph

Similar Bikes

Highest gear

(descending)

Sizing
One Size

3'11" +

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Reviews
MBR
Dartmoor Hornet first ride - MBR

Aug 2018 · Jamie Darlow

Polish brand Dartmoor build bikes attitude; we try and tame their Dartmoor Hornet hardtail. 160mm fork and Plus tyre compatibility.

Highs
  • Hornet frame has decent geometry and can take 2.8in tyres.

Lows
  • Harsh ride jars the experience

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Aluminum

Fork

Manitou Circus Expert

Travel130mm

Spring TypeAir

Shock

N/A

Spring TypeAir

Headset

Dartmoor Blink

Stem

Dartmoor Fury v.3, 45mm length, 31.8mm bar clamp

Handlebar

Dartmoor Tornado Hi, 780mm width, 31.8mm clamp diameter

Saddle

Dartmoor Trail v.2

Seatpost

6061 aluminum, 350mm length

TypeRigid

Pedals

Dartmoor Stream OEM

Grips

Dartmoor Maze Lite, slip-on

Groupset
Rear Derailleur

SRAM X4, 9–speed

Front Derailleur

N/A

Crank

SR Suntour Zeron, 24mm spindle, 170mm length

Shifters

SRAM X5, 9–speed

Cassette

SunRace CSM980, 9-speed, 11-40 tooth

Chain

SunRace CNM94

Chain Guide

N/A

Brakes

Tektro HD-M275, 160mm rotors

TypeHydraulic Disc

Brake Levers

Tektro HD-M275

Wheels
Rims

Dartmoor Shield, 32 hole

Front Hub

Dartmoor Reel, 32 hole, 110x15mm Boost front, 148x12mm Boost rear

Rear Hub

Dartmoor Reel, 32 hole, 110x15mm Boost front, 148x12mm Boost rear

Tires

WTB Vigilante Comp, 26" x 2.3"
