Today’s Deals2025 CTM
AREON GX Comp
A 29″ aluminum frame full suspension trail e-bike with upper mid-range components.
Compare the full range
Manufacturer Price
€3,399($3,955)| Frame | Aluminum |
|---|---|
| Suspension | Full, 140mm front |
| Fork | Suntour XCR Air |
| Shock | X-Fusion |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | SX Eagle |
| Motor | Panasonic 250W 95Nm mid-drive |
| Battery | 820Wh |
| Brakes | Tektro Hydraulic Disc |
| Seatpost | Dropper |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full AREON model range
View Comparison5'1" – 5'6"
5'4" – 5'10"
5'8" – 6'2"
6'0" – 6'9"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | ALU 6061, rear travel 135 mm, S, M, L, XL |
|---|---|
| Fork | Suntour XCR34, AIR, 2CR, DS, 140mm, boost™ 15x110axle Travel: 140mm Spring Type: Air |
| Shock | XFusion 02 PRO RL |
| Headset | NECO H156 |
| Handlebar | CTM N06, 760/1" rise/35mm |
| Saddle | CTM Cloud M |
| Seatpost | EXA Form KSP900 (M-125mm/L,XL-150mm) Type: Dropper |
| Pedals | VPE 537 |
| Rear Derailleur | SRAM SX Eagle |
|---|---|
| Crank | Samox 38T, 170mm |
| Shifters | SRAM SX Eagle/12sp |
| Chain | SRAM SX Eagle brown |
| Brakes | Tektro HDM535 4 piston / rotor 203mm Type: Tektro Hydraulic Disc |
| Rims | WTB ST Tough, 30mm, TCS 2.0, 29", 32H |
|---|---|
| Front Hub | Shimano TC500, CL, F15/R12 thru type axle |
| Rear Hub | Shimano TC500, CL, F15/R12 thru type axle |
| Motor | PANASONIC GX ULTIMATE / 250W / 95Nm |
|---|---|
| Battery | BMZ V10 820Wh / 36V / 22.8Ah |
First added December 7
Last updated November 29
Not listed for 181 days
