Today’s Deals2023 Bombtrack
BEYOND+
A steel frame gravel bike with upper mid-range components and sram level hydraulic disc brakes.
Compare the full range
| Weight | 31.7 lbs |
|---|---|
| Frame | Steel |
| Suspension | Rigid |
| Fork | Steel |
| Wheels | 650b Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | SX Eagle, Truvativ Stylo |
| Brakes | SRAM Level Hydraulic Disc |
5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Aug 2019 · Cass Gilbert
2020 sees a few tweaks to Bombtrack's big-wheeled Beyond+ ADV, including three-pack cage mounts on each seatstay. Here are all the details, the full build kit, and a few thoughts on how it rides.
| Frame | 4130 double butted crmo, TA, rack / fender mounts, Boost spacing, stealth dropper ready, 73 mm BSA BB shell ¹ BB Standard: BSA, 73mm, Threaded Tire Clearance: 3" Color: Matt Warm Grey |
|---|---|
| Fork | BOMBTRACK BPS 4130 crmo, double butted blades, 1.1/2'' - 1.1/8'', fender / rack / triple cage mounts, internal hub dynamo cable routing |
| Bottom Bracket | SRAM DUB BSA 73 mm |
| Headset | Sealed semi integrated / external aheadset, 1.1/2'' - 1.1/8'' |
| Stem | BOMBTRACK TRAMP forged aluminium stem, 3° |
| Handlebar | BOMBTRACK TRAIL flat bar, 31.8 mm, 9° backsweep, 4° upsweep, 7 mm rise |
| Saddle | BOMBTRACK FUZZ |
| Seatpost | BOMBTRACK YEW aluminium seatpost, 30.9 mm x 400 mm Type: Rigid |
| Pedals | - |
| Grips | BOMBTRACK SCROLL grips |
| Rear Derailleur | SRAM SX EAGLE, clutch, long cage |
|---|---|
| Front Derailleur | - |
| Crank | TRUVATIV STYLO 6K aluminium crank, Boost DUB |
| Shifters | SRAM SX-EAGLE 12-speed trigger shifter |
| Cassette | SRAM PG-1210 EAGLE 12-speed, 11 - 50 T |
| Chain | SRAM NX EAGLE chain, 1/2'' x 11/128'', 118L |
| Brakes | SRAM LEVEL hydraulic disc brakes with 180 mm F / 160 mm R rotors Type: SRAM Level Hydraulic Disc |
| Rims | Front: WTB ST i35 double wall, TCS 2.0, 32h, Rear: WTB ST i35 double wall, TCS 2.0, 32h |
|---|---|
| Front Hub | BOMBTRACK GRAD Boost sealed hub, 6-bolt disc |
| Rear Hub | BOMBTRACK GRAD Boost sealed hub, HG driver, 6-bolt disc |
| Tires | Front: WTB RANGER TCS TOUGH / FAST ROLLING 27.5'' x 2.8'', tubeless ready, Rear: WTB RANGER TCS TOUGH / FAST ROLLING 27.5'' x 2.8'', tubeless ready |
| Lights | - |
|---|---|
| Fenders | - |
| Racks | - |
